115
Other Playback Functions (PLAY)
3. Press [2] to display the editing menu and specify one or two cut
points.
4. Use [8] and [2] to select “Yes” and then press [SET].
The selected cut operation will take considerable time to complete. Don’t try to
perform any camera operation until the “Busy... Please wait...” message
disappears from the monitor screen. Note that a cut operation can take a long
time if the movie being edited is long.
IMPORTANT!
When you edit a movie, only the result is saved. The original movie is not retained.
An editing operation cannot be undone.
NOTE
A movie that is shorter than five seconds cannot be edited.
Editing of movies recorded with a different type of camera is not supported.
You will not be able to edit a movie if the amount of remaining memory capacity is
less than the size of the movie file you want to edit. If there is not enough memory
available, delete files you no longer need to free up more.
Splitting of a movie into two movies and splicing of two different movies into a
single movie are not supported.
You also can start a movie editing operation while the movie you want to edit is
playing back. When playback reaches a frame where you want a cut point to be,
press [SET] to pause playback. Next, press [2] to display the menu of editing
options. Perform editing using the same procedures as described above.
Cut
(To-Point Cut)
While the frame you want the cut to be up to is
displayed, press [2].
Cut
(Point-To-Point Cut)
1
While the frame you want the first (From) cut to be is
displayed, press [2].
2
Select another frame.
3
While the frame you want the second (To) cut to be
is displayed, press [2].
Cut
(From-Point Cut)
While the frame you want the cut to be from is
displayed, press [2].
}
~
¡

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio EXILIM EX-ZR100 and is the answer not in the manual?

Casio EXILIM EX-ZR100 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerYes
Total megapixels12.75 MP
Image sensor size1/2.3 \
Image formats supportedJPG
Supported aspect ratios3:2, 16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3264 x 2448, 3648 x 2736, 4000 x 2248, 4000 x 3000
Digital zoom4 x
Optical zoom12.5 x
Combined zoom199.3 x
Focal length range4.24 - 53 mm
Number of aspheric elements1
Lens structure (elements/groups)9/8
Digital SLRNo
Power source typeAC, Battery
Aperture range (F-F)3 - 7.9
Camera shutter speed1- 1/2000 s
Focal length (35mm film equivalent)24 - 300 mm
Auto focusing (AF) modesMulti Point Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (wide)0.01 - 0.5 m
Auto Mode focusing range (wide)0.05 - ∞ m
Light meteringCentre-weighted, Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, Auto
Light exposure modesAperture priority AE, Manual, Shutter priority AE
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Flash modesAuto, Flash off, Red-eye reduction
Scene modesClose-up (macro), Panorama, Portrait, Self-portrait
Photo effects-
White balanceAuto, Daylight, Fluorescent, Manual, Shade, Tungsten
Camera playbackMovie, Single image
Image processorEXILIM Engine HS
Self-timer delay2, 10 s
Camera file systemDCF 2.0, DPOF 1.1, Exif 2.3
Video resolutions640 x 480, 1920 x 1080 pixels
Motion JPEG frame rate3 fps
Video formats supportedH.264, MOV
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Internal memory52.2 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution960 x 480 pixels
Display resolution (numeric)460800 pixels
USB version2.0
Product colorWhite
Battery typeNP-130
Cables includedAC, AV, USB
Weight and Dimensions IconWeight and Dimensions
Depth28.6 mm
Width104.8 mm
Height59.1 mm
Weight165 g
Weight (including battery)205 g
