Page #151 background image
151
Using the Camera with a Computer
If you are running Mac OS X, you can manage snapshots using iPhoto, which comes
bundled with some Macintosh products. If you are running Mac OS 9, you will need to
use commercially available software.
You can use QuickTime, which comes bundled with your operating system, to play
back movies on a Macintosh. To play back a movie, first copy it to your Macintosh
and then double-click the movie file.
. Minimum Computer System Requirements for Movie Playback
The minimum system requirements described below are necessary to play back
movies recorded with this camera on a computer.
The above are recommended system environments. Configuring one of these
environments does not guarantee proper operation.
Certain settings and other installed software may interfere with proper playback of
movies.
Movie file playback is not supported under OS 9.
. Movie Playback Precautions
Proper movie playback may not be possible on some Macintosh models. If you
experience problems, try the following.
Upgrade to the latest version of QuickTime.
Shut down other applications that are running.
Even if proper playback is not possible on your Macintosh, you can use the AV cable
that comes bundled with the camera to connect to the video input terminal of a TV or
Macintosh and play back movies that way.
IMPORTANT!
Be sure to move the movie data to the hard disk of your Macintosh before trying to
play it. Proper movie playback may not be possible for data accessed over a
network, from a memory card, etc.
Transferring Images Automatically and Managing Them on
Your Macintosh
Playing a Movie
Operating System : Image Quality “FHD”:
Mac OS X 10.4.11 or higher
Image Quality “STD” or “HS”:
Mac OS X 10.3.9 or higher
Required Software: QuickTime 7 or higher

Table of Contents

Questions and Answers:

Casio EXILIM EX-ZR100 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerYes
Total megapixels12.75 MP
Image sensor size1/2.3 \
Image formats supportedJPG
Supported aspect ratios3:2, 16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3264 x 2448, 3648 x 2736, 4000 x 2248, 4000 x 3000
Digital zoom4 x
Optical zoom12.5 x
Combined zoom199.3 x
Focal length range4.24 - 53 mm
Number of aspheric elements1
Lens structure (elements/groups)9/8
Digital SLRNo
Power source typeAC, Battery
Aperture range (F-F)3 - 7.9
Camera shutter speed1- 1/2000 s
Focal length (35mm film equivalent)24 - 300 mm
Auto focusing (AF) modesMulti Point Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (wide)0.01 - 0.5 m
Auto Mode focusing range (wide)0.05 - ∞ m
Light meteringCentre-weighted, Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, Auto
Light exposure modesAperture priority AE, Manual, Shutter priority AE
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Flash modesAuto, Flash off, Red-eye reduction
Scene modesClose-up (macro), Panorama, Portrait, Self-portrait
Photo effects-
White balanceAuto, Daylight, Fluorescent, Manual, Shade, Tungsten
Camera playbackMovie, Single image
Image processorEXILIM Engine HS
Self-timer delay2, 10 s
Camera file systemDCF 2.0, DPOF 1.1, Exif 2.3
Video resolutions640 x 480, 1920 x 1080 pixels
Motion JPEG frame rate3 fps
Video formats supportedH.264, MOV
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Internal memory52.2 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution960 x 480 pixels
Display resolution (numeric)460800 pixels
USB version2.0
Product colorWhite
Battery typeNP-130
Cables includedAC, AV, USB
Weight and Dimensions IconWeight and Dimensions
Depth28.6 mm
Width104.8 mm
Height59.1 mm
Weight165 g
Weight (including battery)205 g
