Casio LK-265 User Manual

EN-26
Reference
Specifications
Model LK-190/LK-265/LK-266
Keyboard 61 keys
Touch Response
(LK-265/266 only) 2 types, Off
Key Lighting Maximum number of keys simultaneously lit: 4
Maximum Polyphony 48 notes
Tones
Preset Tones 400; 1 stereo piano tone
Effects Reverb (10 types, Off), Dance Music effects, Virtual Hall (LK-265/266 only)
Metronome
Beat Off, 1 to 9 beats
Tempo 20 to 255
Song Bank
Preset Songs 60
User Songs (LK-265/266 only) Up to 30/Total Memory Capacity: Approximately 32 kilobytes (1 kilob yte = 1,024 bytes)
Easy Mode
Lesson Parts Left hand, right hand, both hands
Other Repeat
Step Up Lesson
Lesson Types 2 (Listen, Follow)
Lesson Parts Left hand, right hand, both hands
Other Repeat, Voice Fingering Guide, Note Guide, Performance Evaluation
Auto Accompaniment
Preset Rhythms 100 types
One Touch Presets 100 types
Dance Music Mode
Preset Patterns 50 types
Demo Function Looped play of the dance music demo (1 song) and built-in Song Bank (60 songs)
Other Functions
Transpose ±1 octave (–12 to 0 to +12 semitones)
Tuning A4 = 415.5 to 465.9Hz (Initial Default: 440.0Hz)
Musical Information System Tone, Auto Accompaniment, Song Bank numbers and names; staff notation; fingering guide;
pedal; tempo; measure number, beat; chord name, etc.
APP Function
(LK-265/266 only)
Supported Devices iOS, Android (connected via the audio input terminal)
Jacks
Sustain jack Standard jack (sustain, sostenuto, soft, rhythm)
PHONES/OUTPUT jack Stereo standard jack × 1
Output impedance: 150 Ω; Output voltage: 4.5 V (RMS) MAX
AUDIO IN jack
(LK-265/266 only)
Stereo mini jack
Input impedance: 9 kΩ; Input sensitivity: 200 mV
Microphone input jack Standard jack (Connect a dynamic microphone.)
Input impedance: 3 kΩ; Input sensitivity: 10 mV
AC adaptor terminal 9.5 V DC
Power Requirements 2-Way Power
Batteries Six AA-size manganese batteries or AA-size alkaline batteries
Battery Life Approximately 6 hours (on alkaline batteries)
AC Adaptor AD-E95100L
Auto Power Off Approximately 30 minutes after last operation; Can be disabled.
LK265_190-ES-1A.indd 28 2016/07/15 10:12:37

Casio LK-265 Specifications

General

Tones quantity	400
RMS rated power	2 W
Number of speakers	2
Metronome tempo range	20 - 255 bpm
Metronome beats per bar	2, 3, 4, 5, 6
Maximum polyphony (notes)	48
Music memory capacity (songs)	60
Reverberation effects quantity	10
Keys quantity	61 keys
Transposition range	-1 - 1 octave(s)
Mobile operating systems supported	Android, iOS
Headphone outputs	1
Headphone connectivity	6.3 mm
AC input voltage	9.5 V
Power consumption (min)	5.5 W
Product color	Black

Weight and Dimensions

Depth	307 mm
Width	946 mm
Height	92 mm
Weight	3600 g
