Reference
E-29
English
• Specifications and designs are subject to change without notice.
Product Specifications
Model PX-135BK/PX-135WE
Keyboard 88-key piano keyboard, with Touch Response
Maximum Polyphony 128 notes
Tones 18
• Layer (excluding bass tones)
• Split (Low-range bass tones only)
Effects Brilliance (–3 to 0 to 3), Reverb (4 types), Chorus (4 types), DSP, Acoustic Resonance
Metronome • Beats: 0, 2, 3, 4, 5, 6
• Tempo Range: 20 to 255
Duet Adjustable tone range (–1 to 2 octaves)
Music Library • Number of Songs: 60, User Songs: 1 (memory capacity; up to 65KB )*
* Based on 1 KB = 1024 bytes, 1 MB = 1024
2
bytes
• Song volume: Adjustable
• Part On/Off: L, R
Recorder • Functions: Real-time recording, playback
• Number of Song: 1
• Number of Tracks: 2
• Capacity: Approximately 5,000 notes total
• Recorded Data Protection: Built-in flash memory
Pedals Damper (Soft and sostenuto pedal operations enabled by the optional SP-32 Pedal Unit.)
Other Functions • Touch Select: 3 types, Off
• Transpose: 2 octaves (–12 to 0 to 12)
• Tuning: A4 = 440.0 Hz ±99 cents (variable)
• Temperament
• Octave shift
• Operation lock
MIDI 16-channel multi-timbre receive
Inputs/Outputs • PHONES jacks: Stereo mini jacks × 2
Output impedance: 3
Ω
Output Voltage: 1.5V (RMS) MAX
• Power: 12V DC
• USB port: TYPE B
• Damper Pedal Jack: Standard jack
• Pedal connector
Speakers [13cm × 6cm (rectangular)] × 2 (Output 8W + 8W)
Power Requirements AC Adaptor: AD-A12150LW
Power Consumption 12V = 18W
Dimensions 132.2 (W) × 28.6 (D) × 13.5 (H) cm (52
1
/
16
× 11
1
/
4
× 5
5
/
16
inch)
Weight Approximately 11.2kg (24.7 lbs)
