5. PARTS LIST: MODULE QW-2634
Note: 1. Prices and specifications are subject to change without prior notice.
2. Spare parts are classified as follows according to their importance in after-sales service.
A Rank ---------------------------------------- Very Important
B Rank ---------------------------------------- Important
C Rank ---------------------------------------
-
Less important
3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basi
s
Batteries in Blister pack will be supplied from our Sales Department.
4. As for order/supply of spare parts, refer to the separate publication "GUIDE BOOK for spare parts supply".
Item Code No. Parts Name Specification Applicable Q R
MODULE/WITHOUT MOVEMENT QW-2634AT-01 STR-600-2V
< The module QW-2634 is "built-in t
yp
e" which is assembled directl
y
to
the case, therefore the module as the s
p
are
p
arts is not available. >
1 1013 1512 LCD C2634-01P
QW-2634AT-01
1A
2 1008 9590 EL YEL-2534-A-00
QW-2634AT-01
1A
3 7640 7246 PCB ASS'Y RJQ516079*001V01TK
QW-2634AT-01
1A
4 1009 7666 CAPACITOR/TRIMMER CTZ2E-25C-W2-P
QW-2634AT-01
1B
5 7110 6323 OSCILLATOR/CRYSTAL DT-26S11
QW-2634AT-01
1B
6 1006 5657 BATTERY/STORAGE CTL1616
QW-2634AT-01
1B
7 7231 1913 CONTACT/BATTERY
(
-
)
Q359948B-2
QW-2634AT-01
1C
8 7218 0438 CUSHION/524 Q411459-1
QW-2634AT-01
1C
9 1008 3364 HOLDER/BATTERY Q254197A-2
QW-2634AT-01
1C
10 1008 2102 HOUSING 2534-2 Q152370-1
QW-2634AT-01
1C
11 1008 2135 INTERCONNECTOR Q469546-1
QW-2634AT-01
2C
12 1006 5664 LABEL 2368 Q468543A-1
QW-2634AT-01
1C
13 7105 5275 SENSOR/TILT TS-2418-P
QW-2634AT-01
1B
14 1009 9862 SHEET/INSULATION Q470524-1
QW-2634AT-01
1C
15 1008 2132 SPACER 2534-1
Q152368-1 QW-2634AT-01
1C
16 1008 2133 SPACER 2534-2 Q152369A-1
QW-2634AT-01
1C
17 7230 0616 SPRING/COIL 1199-1 Q437728B-1
QW-2634AT-01
2B
18 1008 2134 SPRING/COIL 2534-1 Q469421-1
QW-2634AT-01
2B
19 7230 0644 SPRING/COIL 785-1 Q439335-1
QW-2634AT-01
1B
20 1008 4578 SUPPORTER/PCB ASS'Y Q152367-2
QW-2634AT-01
1C
For the
p
rices and minimum order/su
pp
l
y
q
uantities of the above
p
arts, refer to the Parts Price List P.P.L.-603.
Notes: Q - Used quantity
R - Rank
— 11 —
