A-17
Appendix
735A-E-131A
REVERB Effect List
Effect List
CHORUS Effect List
DSP Effect List
Settable parameters depend on the DSP type. Also,
the parameters for each DSP type depend on the
algorithm* associated with the DSP type. See the DSP
Algorithm List on page A-19 for more information.
* Effector structure and operation type
No. Display Name Type Name
00 Chorus 1 Chorus 1
01 Chorus 2 Chorus 2
02 Chorus 3 Chorus 3
03 Chorus 4 Chorus 4
04 FBChorus
Feedback Chorus
05 Flanger1 Flanger 1
06 SDelay 1 Short Delay 1
07 SDelay 2 Short Delay 2
08 SFChorus Soft Chorus
09 BRChorus Bright Chorus
10 DPChorus Deep Chorus
11 Flanger 2 Flanger 2
12 Flanger 3 Flanger 3
13 Flanger 4 Flanger 4
14 SDelay 3 Short Delay 3
15 SDelay 4 Short Delay 4
No. Display Name Type Name
00 Room 1 Room 1
01 Room 2 Room 2
02 Room 3 Room 3
03 Hall 1 Hall 1
04 Hall 2 Hall 2
05 Plate 1 Plate 1
06 Delay Delay
07 PanDelay Pan Delay
08 Plate 2 Plate 2
09 Plate 3 Plate 3
10 LrgRoom 1 Large Room 1
11 LrgRoom 2 Large Room 2
12 Stadium 1 Stadium 1
13 Stadium 2 Stadium 2
14 LongDly 1 Long Delay 1
15 LongDly 2 Long Delay 2
DSP
Algorithm
Display DSP Name
No. ID Name
Dynamics Fx
[00] 03 Equalize Equalizer
[01] 06 Comp 1 Compressor 1
[02] 06 Comp 2 Compressor 2
[03] 07 Limiter Limiter
[04] 13 Enhancer Enhancer Phaser
Phaser
[05] 10 Phaser Phaser
[06] 09 StPhaser Stereo Phaser
Chorus
[07] 16 Chorus 1 Chorus 1
[08] 17 Chorus 2 Chorus 2
[09] 19 Chorus 3 Chorus 3
[10] 18 Chorus 4 Chorus 4
[11] M05 Enha Cho Enhancer - Chorus
Flanger
[12] 26 Flanger Flanger
[13] M07 EnhaFlan Enhancer - Flanger
Equalizer List
No. Display Name Type Name
0 Standard Standard
1 Bass + Bass +
2 Treble + Treble +
3 Loundness Loundness
4 Mellow Mellow
5 Bright Bright
6 Rock Rock
7 Dance Dance
8 Jazz Jazz
9 Classic Classic
WK3000_e_A-17-18.p65 04.3.26, 0:12 PM17
To Next Page
