1.1.20 Rollover protective structure
Do not make any mod
ifications to the rollover
protective structure (ROPS) as this will change
protection provided. Do not change structure by
welding, cutting, adding weight, or drilling holes
into structure.
Any change not specifically authorized by AGCO
invalidates AGCO certification for ROPS. The
protection oered by ROPS will be impaired if
ROPS has structural damage or alteration. Damage
to structure can be caused by a turn over or by
falling objects.
Do not mount items (fire extinguishers, first aid
kits, work lights, etc.) by welding brackets or
drilling holes in ROPS. See dealer for mounting
guide lines.
TRHJA0110319901
Original art: ~/Desktop/Graphics/ST4/ACW3549100-1-ECN220604-.pdf
GUID-7998C354-06FC-455A-8D67-77F8F85E1A45-low.svg [Low]
Fig. 7
1.1.21 Burn prevention
Do not touch any part of an operating engine.
Ot
her components such as the transmission, the
axles and the oil reservoir can also be hot. Let the
engine cool before performing any maintenance on
the engine. Release all pressure in air, oil,
lubrication, fuel and cooling systems before
disconnecting any line fittings or related items.
GUID-81A39ABC-001C-4617-A089-FC6F702EF934-high.jpg [High]
Fig. 8
1.1.22 Coolant
When the engine is at operating temperature, the
engine coolant is hot. T
he coolant is also under
pressure. The radiator and all the lines to the
heater or engine contain hot coolant.
Any contact with hot coolant or with the steam
can cause severe burns. Allow the cooling system
components to cool before the cooling system is
drained.
Check the coolant level only after the engine has
been stopped.
Make sure the filler cap is cool before removing.
The filler cap must be cool enough to touch with a
bare hand. Remove the filler cap slowly to relieve
the pressure.
The cooling system conditioner contains alkali.
Alkali can cause personal injury.
Do not allow alkali to contact skin, eyes or mouth.
