Electrical Component and Inline Harness Connector End Views 7-285
Inline Harness Connector End Views
X101 Engine Chassis Harness to Engine Harness
4204560 3960400
Connector Part Information
Harness Type: Engine Chassis
OEM Connector: 13929980
Service Connector: 19333092
Description: 36-Way F 1.5, 2.8 CTS, 6.3 MCP Series,
Sealed (BK)
Connector Part Information
Harness Type: Engine
OEM Connector: 13594541
Service Connector: 19330685
Description: 36-Way M 1.5, 2.8, 5.8 Series, Sealed (BK)
Terminal Part Information
Terminal
Type ID
Terminated
Lead
Diagnostic
Test Probe
Terminal
Removal Tool
Service Terminal Tray
Name
Core
Crimp
Insulation
Crimp
I 19301776
J-35616-
14 (GN)
J-38125-215A Not Available
Not
Required
Not
Required
Not
Required
II 19329758
J-35616-
14 (GN)
J-38125-215A Not Available
Not
Required
Not
Required
Not
Required
III 19332901
J-35616-
35 (VT)
J-38125-215A Not Available
Not
Required
Not
Required
Not
Required
IV 19368624
J-35616-
35 (VT)
J-38125-215A Not Available
Not
Required
Not
Required
Not
Required
V 13575380
J-35616-
3 (GY)
EL-38125-560-A Not Available
Not
Required
Not
Required
Not
Required
VI 13575574
J-35616-
5 (PU)
J-38125-215A Not Available
Not
Required
Not
Required
Not
Required
VII 19368136
J-35616-
3 (GY)
EL-38125-560-A Not Available
Not
Required
Not
Required
Not
Required
X101 Engine Chassis Harness to Engine Harness
Pin Size Color Circuit Terminal
Type ID
Option Function Pin Size Color Circuit Terminal
Type ID
Option
1 0.5
D-
BU/
BN
4498 II —
High Speed
GMLAN
Serial Data
[+] 7
1 0.5
BU/
BN
4498 VII —
2 0.5 WH 4499 II —
High Speed
GMLAN
Serial Data
[-] 7
2 0.5 WH 4499 VII —
3 0.5 D-BU 2500 I —
High Speed
GMLAN
Serial Data
[+] 1
3 0.5 BU 2500 VII —
2021 - Silverado 4500HD, 5500HD, and 6500HD Electrical Body Builder Manual
