Cisco ASR 1000 Series Hardware Installation And Configuration Guide

2-4
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation and Initial Configuration Guide
OL-13208-01
Chapter 2 Cisco ASR 1000 Series Routers Components
Cisco ASR 1000 Series Route Processor 1
Table 2-1 lists the Cisco ASR 1000 Series RP1 LEDs and behaviors.
Table 2-1 Cisco ASR 1000 Series Route Processor 1 LEDs
No. LED Label LED Color —State Behavior Description
1 PWR Power Solid green All power requirements are within
specification
Off Off, the router is in standby mode.
2 STAT System status Solid green Cisco IOS has successfully booted.
Yellow ROMMON is running or when the
Process Manager declares that a
critical ASR 1000 Series RP1
process is not running
Red System failure or powering up.
3 ACTV Active Green Lit when this is the active Cisco
ASR 1000 Series RP1.
4 STBY Standby Yellow Lit when this is the standby
ASR1000 Series RP1.
5 CRIT* Critical Solid Red Critical alarm indicator. For
example: Ambient air temperature
is above 60ºC and will begin
shutdown in 5 minutes.
6 MAJ* Major Solid Red Major alarm indicator. For
example: Ambient air temperature
is beyond short term operating
range of 55ºC. System will shut
down above 60ºC.
7 MIN* Minor Amber Minor alarm indicator. Ambient air
temperature is beyond normal
operating range of 40ºC. For
example: if the RP software deter-
mines that an unknown card has
been installed or if the card has
failed, the card can power it off or
set a minor alarm.
8 DISK HD Internal hard drive
LED
Flashing Green Active indicator.
Off No activity.
9 DISK USB External USB Flash
LED
Flashing Green Active indicator.
Off No activity.
10 DISK BF Internal USB
bootflash LED
Flashing Green Active indicator.
Off No activity.
11 CARRIER LED Off Out of service or not configured.
Solid Green In frame and working properly.
Amber Fault of loop condition exists.
