Cisco C9200L-24T-4X User Manual

Weight does not include the functional uplink modules, the blank modules, or the power supplies
Table 18: Weight Measurements
WeightSwitch Model
10 lb (4.5 kg)C9200-24T
10 lb (4.5 kg)C9200-24P
10 lb (4.5 kg)C9200-48T
10 lb (4.5 kg)C9200-48P
9.6 lb (4.35 kg)C9200L-24T-4G
9.6 lb (4.35 kg)C9200L-24P-4G
9.6 lb (4.35 kg)C9200L-48T-4G
9.6 lb (4.35 kg)C9200L-48P-4G
9.0 lb (4.08 kg)C9200L-48T-4X
9.5 lb (4.31 kg)C9200L-48P-4X
8.5 lb (3.9 kg)C9200L-24P-4X
8.0 lb (3.63 kg)C9200L-24T-4X
This table describes the physical specifications.
Table 19: Physical Specifications for the Power Supplies
Weight
2 lb (0.9 kg)
PWR-C5-1KWAC
1.7 lb (0.77 kg)PWR-C5-600WAC
1.5 lb (0.68 kg)PWR-C5-125WAC
Dimensions (H x D x W)
The dimensions shown include the extraction handle and the keying feature.
1.58 x 4.0 x 7.6 in. (40.1 X 101.6 X 193 mm)
PWR-C5-1KWAC
PWR-C5-600WAC
PWR-C5-125WAC
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
71
Technical Specifications
Technical Specifications

Cisco C9200L-24T-4X Specifications

General

Model	C9200L-24T-4X
Device Type	Switch
Enclosure Type	Rack-mountable
Subtype	Gigabit Ethernet
Switching Capacity	128 Gbps
Forwarding Rate	95.23 Mpps
DRAM	4 GB
Flash Memory	4 GB
Power Device	Internal power supply
Ports	24 x 10/100/1000
Uplink Interfaces	4 x 10 Gigabit SFP+
MAC Address Table Size	16, 000 entries
Jumbo Frame Support	9198 bytes
Routing Protocol	OSPF, BGP, EIGRP, RIP
Remote Management Protocol	SNMP 1, SNMP 2, SNMP 3, RMON, SSH, Telnet, HTTP, HTTPS
Features	VLAN support, Quality of Service (QoS), ACL support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ae
Voltage Required	AC 120/230 V (50 - 60 Hz)
Stacking	Stackable
Operating Temperature	32 to 104°F (0 to 40°C)
