Cisco Catalyst 1900 Series User Manual

7 GND  Ground
8 DCD > Data Carrier Detect (always on)²
20 DTR < Data Terminal Ready
Shield GND  Shield Ground
¹Pins 4 and 5 are connected.
²Pins 6 and 8 are connected.
