CHAPTER 1
Product Overview
• Chassis Overview, on page 1
• Fan Tray Assembly, on page 3
• Power Supply Module Overview, on page 6
Chassis Overview
The Cisco Catalyst 9606R Switch is a six-slot chassis, with two redundant supervisor module slots, four
module slots, four power supply modules and a fan tray.
Table 1: Cisco Catalyst 9600R Switch Features
DescriptionFeature
Cisco Catalyst 9606RProduct ID
Has six horizontal slots. Slots are numbered 1 to 6 from top to bottom.Chassis
Supports two supervisor modules. The following is the supported model
— Cisco Catalyst 9600 Series Supervisor 1 Module (C9600-SUP-1).
For more information about installing a supervisor module, see the Cisco
Catalyst 9600 Series Switch Supervisor Module Installation Note.
Supervisor modules
Supports upto four line cards. The following are the supported line cards:
• Cisco Catalyst 9600 Series 48-Port 25GE/10GE/1GE
1
(C9600-LC-48YL — 48 ports that support SFP56 (48x1G/10G/25G
ports)
• Cisco Catalyst 9600 Series 24-Port 40GE/12-Port 100GE
(C9600-LC-24C) — 24 ports that support QSFP28 (24x40G or
12x100G)
For more information about installing a line card, see the Cisco Catalyst
9600 Series Switch Line Card Installation Note.
Line Cards
Provides a single front and rear serviceable and hot-swappable fan tray
with 9 fans.
Fan tray assembly
Cisco Catalyst 9600 Series Switches Hardware Installation Guide
1
