Cisco Catalyst Express 500 User Manual

1-5
User Guide for the Catalyst Express 500 Switches
OL-8122-01
Chapter 1 Introduction
Features and Benefits
Hardware Features
Figure 1-2 and the list that follows describe the switch hardware features and the
benefits that they provide. All switches can be installed on a table top, in a rack,
or mounted on a wall. For hardware installation information, see the “Install the
Switch” section on page 2-5.
Figure 1-2 Catalyst Express 500 Hardware Overview
Catalyst Express 500
SERIES
2
1
1X
2X
P
O
W
E
R
O
V
E
R
E
T
H
E
R
N
E
T
11X
12X
4
3
6
5
8
7
10
9
12
11
14
13
13X
14X
23X
24X
16
15
18
17
20
19
22
21
24
23
25
25
26
26
SY
ST
EM
A
LE
R
T
P
oE
SETUP
SYSTEM
ALERT
PoE
SETUP
AC power connector
Security cable slot
side and rear panels
Power over Ethernet
(PoE) ports supply up to
15.4 W per port
Fast Ethernet ports
Dual-purpose uplink ports:
SFP module and
10/100/1000BASE-T
SETUP button
Port LEDs
Autonegotiate and auto-MDIX
enabled on all ports
Switch LEDs:
SYSTEM - switch status
ALERT - events detected
PoE - PoE status
SETUP - setup mode
