Use a ratcheting torque flathead screwdriver to torque the power connector captive screws to 5 in-lb
(0.6 N-m), the maximum recommended torque.
Caution
To install or replace the SD card, follow these steps:
1. On the front of the device, locate the door that protects the SD card slot. Loosen the captive screw at the
top of the door using a Phillips screwdriver to open the door.
• To install a card, slide it into the slot, and press it in until it clicks in place. The card is keyed so that
you cannot insert it the wrong way.
• To remove the card, push it in until it releases for it to pop out. Place it in an antistatic bag to protect
it from static discharge.
2. After the card is installed, close the guard door and fasten the captive screw using a Phillips screwdriver
to keep the door in place.
Alarm Ports
The Cisco ISA 3000 has alarm ports. There are two conditions that generate an alarm:
• When dual power supply is configured, and there is a failed or missing power supply.
• When the CPU temperature is in critical condition (below -40°C or above 105°C)
When either condition is met, the alarm LED turns red, and a syslog message and SNMP trap is triggered.
Check the software guide for the operating system you are running for information on alarm port support.
Note
Power Supply
The device can be configured to run dual power supplies. When set, the system expects to see both power
supplies functioning properly.
Check the software guide for the operating system you are running for information on dual power supply
configuration and support.
Note
When configured for dual power supply, and a failure occurs, the Alarm Out LED turns red. The alarm relay
is also energized. A syslog message is generated:
Syslog: %ASA-1-735006: Power Supply Unit Redundancy Lost
When configured for dual power supply, and a failure recovers, the Alarm Out LED turns off. A syslog
message is generated:
Syslog: %ASA-1-735005: Power Supply Unit Redundancy OK
Product Overview
11
Product Overview
Alarm Ports
