Cisco MDS 9148T User Manual

Step 4 If you have attached a grounding wire to the chassis grounding pad, connect the other end of the wire to the facility
ground.
Grounding the Switch
The switch chassis is automatically grounded when you install the switch properly in a grounded rack with
metal-to-metal connections between the switch and rack.
Alternatively, you can ground the chassis (this is required if the rack is not grounded) by attaching a
customer-supplied grounding cable to the chassis grounding pad and the facility ground.
This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence
of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician
if you are uncertain that suitable grounding is available. Statement 1024
Warning
When installing or replacing the unit, the ground connection must always be made first and disconnected last.
Statement 1046
Warning
Step 1 Use a wire-stripping tool to remove approximately 0.75 in. (1.9 cm) of the covering from the end of the grounding wire.
Step 2 Insert the stripped end of the grounding wire into the open end of the grounding lug, and use a crimping tool to crimp
the lug to the wire. Verify that the ground wire is securely attached to the grounding lug by attempting to pull the wire
out of the crimped lug.
Step 3 Remove the label covering the grounding pad on the chassis. Secure the grounding lug to the chassis grounding pad with
two M4 screws, and tighten each screw to 11.5 to 15 in-lb (1.3 to 1.7 N·m) of torque.
Cisco MDS 9148T 32-Gbps 48-Port Fibre Channel Switch Hardware Installation Guide
33
Installing the Cisco MDS 9148T Switch
Grounding the Switch
