Smartport
Common Smartport Tasks
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 205
11
STEP 4 Set the macro parameters as required.
STEP 5 Click Apply.
Workflow3: To adjust Smartport macro parameter defaults and/or bind a user-defined
macro pair to a Smartport type, perform the following steps:
Through this procedure you can accomplish the following:
• View the macro source.
• Change parameter defaults.
• Restore the parameter defaults to the factory settings.
• Bind a user-defined macro pair (a macro and its corresponding anti-macro) to a
Smartport type.
STEP 1 Open the Type Settings page.
STEP 2 Select the Smartport Type.
STEP 3 Click View Macro Source to view the current Smartport macro that is associated with the
selected Smartport Type.
STEP 4 Click Edit to open a new window in which you can bind user-defined macros to the selected
Smartport type and/or modify the default values of the parameters in the macros bound to that
Smartport type. These parameter default values are used when Auto Smartport applies the
selected Smartport type (if applicable) to an interface.
STEP 5 In the Edit page, modify the fields.
STEP 6 Click Apply to return the macro if the parameters changed.
Workflow4: To rerun a Smartport macro after it has failed, perform the following
steps:
STEP 1 In the Interface Settings page, select an interface with Smartport type Unknown.
STEP 2 Click Show Diagnostics to see the problem.
STEP 3 Troubleshoot, then correct the problem. Consider the troubleshooting tip below.
STEP 4 Click Edit. A new window appears in which you can click Reset to reset the interface.
