Cisco SG220-26 Administration Guide

Multicast Forwarding
Configuring IP Multicast Group Addresses
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 168
14
STEP 3 Click Apply. The Multicast properties are defined, and the Running Configuration is
updated.
Configuring IP Multicast Group Addresses
Use the IP Multicast Group Address page to query and add IP Multicast groups.
To define and view IP Multicast groups:
STEP 1 Click Multicast > IP Multicast Group Address.
STEP 2 Enter the query criteria:
• VLAN ID equals to—Define the VLAN of the group to be displayed.
• IP Version equals to—Select either Version 4 or Version 6.
• IP Multicast Group Address equals to—Define the IP address of the
Multicast group to be displayed.
STEP 3 Click Go. The IP Multicast group addresses that match the criteria are displayed.
STEP 4 To add a static IP Multicast group address, click Add.
NOTE Member ports for a static IP multicast group address can be configured
statically only.
STEP 5 Enter the following information:
• VLAN ID—Select the VLAN for the group to be added.
• IP Version—Select either Version 4 or Version 6.
• IP Multicast Group Address—Enter the IP address of the new Multicast
group.
STEP 6 For each port, select its association type. The options are:
• Static—Attaches the port to the Multicast group as a static member.
• None—Indicates that the port is not currently a member of this Multicast
group on this VLAN.
