Important Notes for installing the IX5000 and IX5200
• Installation of the IX system is very different than the TX9000, CTS-3000, or CTS-3010 systems, even though
the components are similar.
• Display installation is completely different. The displays rest on shelves and levelers in the endpoint structure.
The display spools are only used to to adjust the front-back position of the outer edge of the left and right
display. Measure spool distance carefully before installing the displays or the spool cannot drop into its
place in the display frame. You can adjust the spools inward or outward after installation.
• Each cable has a reference designator (printed label) attached to each end. When installing cables, check
the cabling diagram and make sure that each reference designator on the cable corresponds to the correct
reference designator on the electrical component in the table or endpoint structure.
• In many cases, you cannot use a power driver when installing fasteners (screws). Use a manual screwdriver
instead. Do not use a power driver when installing the following components:
• The speakers and speaker blocks
• Any component that uses captive screws (the cable runner and speaker cover)
• Many of the thermoformed and PET outer panels
Follow the instructions in the manual when installing these parts.
• In this manual, Left or Right always means “left or right as viewed from the front of the system”.
