IX5000 Field-Replaceable Units and Country- and Region-Specific Power Connectors
List of Field-Replaceable Units
CTS-5K-BZL-KIT= Vertical bezel extrusions and horizontal display trim
CTS-5K-CAM-CLSTR= Camera
CTS-5K-CAM-HS= Camera lens hood (camera cover)
CTS-5K-CAM-TOOL= Camera targets
CTS-5K-CBL-70DSP= CTS-IX5000 Cable kit for main the main displays
1
H1, H2, H3, D20, D19, D23
CTS-5K-CBL-CODEC= CTS-IX5000 Cable kit for the Encoder/Decoder
codec
1
USB1, iPass, D24
CTS-5K-CBL-CUP= Presentation cable cup
CTS-5K-CBL-EP= CTS-IX5000 Cable Kit for speaker, lights and camera
1
L1, L2, L3, L4, L5, L6, DP1
CTS-5K-CBL-HOST= CTS-IX5000 Cable kit for the Host CPU
1
DP2, DP3, AX1, D22
CTS-5K-CBL-R1-AC= CTS-IX5000 Cable kit, front row AC cables
1
CTS-5K-CBL-R1-LAP= CTS-IX5000 Cable kit, front row table Ethernet
Lapconns
1
CX1, C1-C6
CTS-5K-CBL-R1-MIC= CTS-IX5000 Cable kit, front row table audio
1
A1-A6
CTS-5K-CBL-R1-SW= CTS-IX5000 Cable kit, front row table switch
1
EX1
CTS-5K-CBL-R2-AC= CTS-IX5000 Cable kit, back row AC cables
1
CTS-5K-CBL-R2-LAP= CTS-IX5000 Cable kit, back row table Ethernet
Lapconns
1
CX2, C7-C18
CTS-5K-CBL-R2-MIC= CTS-IX5000 Cable kit, back row table audio
1
AX2, AX3, A7-A18
CTS-5K-CBL-R2-SW= CTS-IX5000 Cable kit, back row switches
1
EX2, EX3
CTS-5K-CBL-RTR= Presentation cable with three-headed
connector—includes cable and cable retractor
L7, L8
CTS-5K-CBL-RUN= Cable runner assembly (includes cable runner and
cable runner cover)
CTS-5K-CBL-RUN-A= 42-inch data display bracket and cable runner kit
CTS-5K-CBL-SUBW= CTS-IX5000 Cable Kit for the Subwoofer
1
USB2, A28, A29, D21
CTS-5K-DISP42= 42-inch data display
CTS-5K-ENCODER-CH= Encoder/Decoder codec—China only
CTS-5K-ENCODER++= CTS-IX5000 TAA Encoder / Decoder for US only
CTS-5K-ENCODER= Encoder/Decoder codec—all countries except China
CTS-5K-EP-HW-KIT= Endpoint hardware kit
CTS-5K-EP-PDU= Endpoint Power Distribution Unit (PDU)
CTS-5K-FAB-PNL-B= Outer leg panels
CTS-5K-FAB-PNL-EP= Endpoint PET plastic panels (includes left, right,
center top, and center bottom PET panels)
CTS-5K-FAB-PNL-F= Front row outer leg panels
CTS-5K-FASCIA-KIT= Top and bottom fascia
CTS-5K-HOSTCPU-CH= Host CPU codec—China only
Table 1 List of Field-Replaceable Units (continued)
FRU Name Description Diagram Reference
