Cisco WAP121 Specifications

General

Modulation	OFDM
Frequency band	2.4 GHz
Number of users	16 user(s)
Channels quantity	13 channels
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3u
Receiver sensitivity	802.11b: 11Mbps@-86dBm 802.11g: 54Mbps@-71dBm 802.11n: 300Mbps@-64dBm
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Networking features	Fast Ethernet
Supported data transfer rates	10/100 Mbit/s
Internal	No
Certification	FCC B, CE, IC, Wi-Fi
LED indicators	LAN, WLAN
Cable lock slot type	Kensington
Supported network protocols	IPv4, IPv6, NTP
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, HTTPS, WEP, WPA, WPA2
Power requirements	12V 0.5A DC
Cables included	LAN (RJ-45)
Compatible operating systems	Linux
Switch type	Managed
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	168 g
Dimensions (WxDxH)	124.17 x 124.17 x 35 mm
