Citizen CL-S300 User Manual

2-2. Installing the label roll holder
1. Pull the label roll
holder out as far as
it will go.
2. Fold out the label
supply hub as
shown in the
illustration.
3. Now rotate the label
roll holder to return
the label supply hub
to its original
position. Press
down the label
supply hub until it
clicks into place.
A. To load label stock
with a 1" core, the
locking notch must
be at the top of the
label supply hub.
B. To load label stock
with a 1.5" core, the
locking notch must
be at the bottom of
the label supply
hub.
【 Note 】
The hub is also marked
on both sides to indicate
the core size, as shown
in the illustration.
1" core
1.5" core
11

Citizen CL-S300 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum printing width	108 mm
USB port	Yes
Ethernet LAN	No
USB 2.0 ports quantity	1
Product color	Black
Media thickness	0.06 - 0.2 mm
Maximum label width	38.1 mm
Maximum label length	1.727 m
Maximum roll diameter	127 mm
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	222 mm
Width	168 mm
Height	178 mm
Weight	2000 g
