CONNECTIONS FOR POWER AND SPEAKERS
The rear panel of the APX200.2 and APX400.2 both contain power and speaker
connections as shown below
.
5
1. Left Speaker Output
2. Right Speaker Output
3. Remote
T
urn-on Input
4. Ground Input
5. Battery + 12v Input
6. 25 Amp Fuse / 40 Amp
Fuse
Figure 2-
4
6
