Clarion CZ200E User Manual

25
English
/ /
•Connectingtotheexternalamplier
External ampliers can be connected to the 4 channel RCA output connections.
Ensure that the connectors are not grounded or shorted to prevent damage to the
unit.
8) Connecting the accessories
Fuse 15A
ANTENNA
(Black)
Refer to next page.
A
B
C
2
4
6
8
1
3
5
7
1
3
5
7
2
4
6
8
A
B
C
16
14
12
10
8
6
4
2
15
13
11
9
7
5
3
1
1
3
5
7
2
4
6
8
1
3
5
7
2
4
6
8
Battery +
Phone Mute
Front left +
Rear left +
ACC +
AMP Remote
Ground
Phone Mute / Brown Rear right (+) / Purple
Rear right (-) / Purple with black stripe
Rear left (+) / Green
Rear left (-) / Green with black stripe
Front right (+) / Grey
Front right (-) / Grey with black stripe
Front left (+) / White
Front left (-) / White with black stripe
Battery 12V(+) / Yellow
Remote On / Blue with white stripe
ACC+ / Red
Ground / Black
Illumination / Orange with white stripe
Illumination
Rear right -
Front right -
Rear left -
Front left -
Front right +
Rear right +
Rear audio output (Right)
Subwoofer output 2
Black
Red
Rear Right / SUB OUT 2
Rear audio output (Left)
Subwoofer output 1
Black
White
Rear Left / SUB OUT 1
Black
Black
Steering wheel
control terminal
SWC
4 Channel Amplifier
Red
White
Right
Left
Front audio
output terminal
Gray
USB connector
Black
YellowYellow
RedRed
For VW and Audi: Change wiring like above.
