Clarion DB345MP Service Manual

DB345MP/DB346MPDB345MP/DB346MP
DB345MP/DB346MPDB345MP/DB346MP
DB345MP/DB346MP
- 10 -- 10 -
- 10 -- 10 -
- 10 -
7 331-3609-00 HOOK PLATE 1
8 716-0778-00 WAVE SCREW (2 X 6) 2
9 335-5915-20 HOOK 1
10 341-1627-20 SHAFT 1
11 750-3219-20 SPRING 1
12 074-1237-76 OUTLET SOCKET 1
13 074-1316-12 OUTLET SOCKET (DCP) 1
14 816-2640-60 FLAT WIRE 1
15 331-3630-00 CONNECTOR COVER 1
16 013-3932-01 TACT SWITCH 1
17 880-2090R TUNER 1
18 331-1861-21 EARTH PLATE 1
19 -------------------- MAIN PWB 1
20 076-0349-04 CONNECTOR 1
21 854-4569-60 EXTENSION LEAD 1
22 313-1873-00 HEAT SINK 1
23 331-3631-00 RCA BRKT 1
24 075-0388-00 RCA JACK 1
25 074-1214-00 OUTLET SOCKET 1
26 009-9006-60 CHOKE 1
27 331-3367-01 IC HOLDER 1
28 051-2042-00 POWER IC 1
29 092-4000-51 ANT-RECEPT 1
30 313-1872-05 HEAT SINK 1
31 855-8000-08 RCA PIN CORD 1
32 345-3799-0L RUBBER PART 2
33 331-3637-00 BRACKET 1
34 716-1753-10 SCREW (M3 X 6) 1
35 335-0833-01 CABLE TIE 1
36 714-2012-81 MC SCREW (M2 X 12) 1
37 731-3008-80 TAPTIGHT (M3 X 8) 4
38 714-3006-81 TAPTIGHT (M3 X 6) 2
39 731-3012-80 TAPTIGHT (M3 X 12) 2
40 286-6310-00 SET PLATE (PE-2640B-A) 1
286-6311-00 SET PLATE (PE-2640K-A) 1
41 311-1848-00 LOWER CASE 1
42 310-1775-05 UPPER CASE 1
43 731-3005-81 TAPTIGHT (M3 X 5) 3
44 331-3607-00 MECHA BRACKET 2
45 714-2604-81 MC SCREW (M2.6 X 4) 3
46 929-0290-80 CD MECHA 1
47 331-3366-00 MECHA BRACKET 1
NO. PART NO. DESCRIPTION Q'TY
1 DCP-465-600 DCP ASSY (PE-2640B-A) 1
DCP-472-800 DCP ASSY (PE-2640K-A) 1
1-1 716-0872-03 SCREW (PE-2640B-A) 2
716-0872-00 SCREW (PE-2640K-A) 2
1-2 371-5770-00 FACE PLATE(R)(PE-2640B-A) 1
371-5770-01 FACE PLATE(R)(PE-2640K-A) 1
1-3 371-5771-00 FACE PLATE (L)(PE-2640B-A) 1
371-5771-01 FACE PLATE (L)(PE-2640K-A) 1
1-4 382-6923-00 RELEASE BUTTON (PE-2640B-A) 1
382-6924-00 RELEASE BUTTON (PE-2640K-A) 1
1-5 750-6747-00 SPRING 1
1-6 382-6925-00 BUTTON ASSY (R) 1
1-7 335-7140-00 ILLUMI PLATE (R) 1
1-8 347-7208-00 STICKER 2
1-9 382-6926-00 BUTTON ASSY (L) 1
1-10 382-6924-00 ILLUMI PLATE (L) 1
1-11 335-7139-00 REAR COVER 1
1-12 716-0872-11 SP SCREW (M1.7 X 6) 4
1-13 331-3749-00 LCD COVER 1
1-14 379-1278-41 INDICATOR (LCD) 1
1-15 347-7092-00 FILM 1
1-16 347-7093-00 SHADE 1
1-17 335-7190-00 LCD ILLUMI 1
1-18 001-7046-00 DIODE 1
1-19 335-7192-00 LCD HOLDER 1
1-20 016-9900-92 VR W/SHAFT 1
1-21 345-7148-20 LAMP CAP 4
1-22 017-0410-00 PILOT LAMP (14V 40mA) 4
1-23 013-6005-51 TACT SWITCH 12
1-24 013-6305-50 TACT SWITCH 3
1-25 060-4008-00 IR-RECEIVER 1
1-26 347-7026-00 BLACK MATTEE STICKER 1
1-27 076-0703-12 PLUG 1
1-28 051-6013-50 IC 1
1-29 -------------------- MAIN PWB (SWITCH) 1
1-30 947-0544-60 ES-DIAL-ASSY(PE-2640B-A) 1
947-0545-60 ES-DIAL-ASSY(PE-2640K-A) 1
1-31 947-0543-60 VOL-KNOB-ASSY 1
2 346-0097-00 LEATHER SHEET 1
3 714-2606-87 MC SCREW (M2.6 X 6) 2
4 370-6101-00 INNER ESC 1
5 382-4078-20 BUTTON P-UP 1
6 750-3173-00 SPRING 2
NO. PART NO. DESCRIPTION Q'TY
