Clarion DB345MP Service Manual

DB345MP/DB346MPDB345MP/DB346MP
DB345MP/DB346MPDB345MP/DB346MP
DB345MP/DB346MP
- 13 -- 13 -
- 13 -- 13 -
- 13 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ELECTRICAL PARTS LIST
Main PWB Section (B1)
Remarks:- #: For PE-2640B-A only @: For PE-2640K-A only
REF No. PART No. DESCRIPTION
Note:- Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
ANT101 092-4000-51 ANT-RECEPT
BL101 880-2090R TUNER
C101 166-2201-50 50V 22pF
C102 166-2201-50 50V 22pF
C103 168-1032-55 50V 0.01uF
C104 168-1032-55 50V 0.01uF
C105 168-1032-55 50V 0.01uF
C106 187-1073-25 10V 100uF
C107 168-1045-56 25V 0.1uF
C108 168-1032-55 50V 0.01uF
C109 187-4763-35 16V 47uF
C110 187-1073-25 10V 100uF
C111 168-1032-55 50V 0.01uF
C112 168-6822-55 50V 6800pF
C113 168-2732-55 50V 0.027uF
C114 168-2732-55 50V 0.027uF
C115 168-1022-55 50V 1000pF
C116 168-4732-78 50V 0.047uF
C117 187-1053-65 50V 1uF
C118 168-1232-55 50V 0.012uF
C126 166-1011-50 50V 100pF
C127 168-1045-56 25V 0.1uF
C128 168-1032-55 50V 0.01uF
C129 168-1045-56 25V 0.1uF
C201 042-1598-90 10V 470uF
C202 168-6832-78 50V 0.068uF
C203 166-1501-50 50V 15pF
C204 166-1501-50 50V 15pF
C206 168-1532-55 50V 0.015uF
C207 168-6832-78 50V 0.068uF
C208 042-1598-90 10V 470uF
C209 178-2242-78 25V 0.22uF
C210 168-1032-55 50V 0.01uF
C211 168-1032-55 50V 0.01uF
C212 168-1032-55 50V 0.01uF
C213 168-1032-55 50V 0.01uF
C215 168-1032-55 50V 0.01uF
C216 168-1032-55 50V 0.01uF
C401 168-2232-55 50V 0.022uF
C402 168-1022-55 50V 1000pF
C405 168-1032-55 50V 0.01uF
C406 168-1045-56 25V 0.1uF
C501 187-2253-65 50V 2.2uF
C502 187-2253-65 50V 2.2uF
C503 187-2253-65 50V 2.2uF
C504 178-4742-78 25V 0.47uF
C505 168-1045-56 25V 0.1uF
C506 168-1045-56 25V 0.1uF
C507 168-2722-55 50V 2700pF
C508 168-1032-55 50V 0.01uF
C510 168-2222-55 50V 2200pF
C511 187-2253-65 50V 2.2uF
C512 187-2253-65 50V 2.2uF
C513 187-2253-65 50V 2.2uF
C514 178-4742-78 25V 0.47uF
C515 168-1045-56 25V 0.1uF
C516 168-1045-56 25V 0.1uF
C517 168-2722-55 50V 2700pF
C518 168-1032-55 50V 0.01uF
C520 168-2222-55 50V 2200pF
C521 187-2263-35 16V 22uF
C523 187-1073-15 6.3V 100uF
C524 187-1063-35 16V 10uF
C530 168-1032-55 50V 0.01uF
C531 166-1011-50 50V 100pF
C532 166-1011-50 50V 100pF
C533 166-1011-50 50V 100pF
C534 166-1011-50 50V 100pF
C535 166-1011-50 50V 100pF
C537 166-1011-50 50V 100pF
C538 168-1022-55 50V 1000pF
C539 166-1011-50 50V 100pF
C551 187-1063-35 16V 10uF
C552 166-4711-50 50V 470pF
C553 187-1063-35 16V 10uF
C554 166-4711-50 50V 470pF
C581 187-1063-35 16V 10uF
C582 166-4711-50 50V 470pF
C583 187-1063-35 16V 10uF
C584 166-4711-50 50V 470pF
C602 178-3932-78 25V 0.039uF
C603 178-3932-78 25V 0.039uF
C612 178-3932-78 25V 0.039uF
C613 178-3932-78 25V 0.039uF
C622 187-1063-35 16V 10uF
C623 178-4742-78 25V 0.47uF
C624 187-1053-65 50V 1uF
C625 168-2222-55 50V 2200pF
C626 168-2222-55 50V 2200pF
C627 168-2222-55 50V 2200pF
C628 168-2222-55 50V 2200pF
C629 168-2222-55 50V 2200pF
C630 168-2222-55 50V 2200pF
C631 168-2222-55 50V 2200pF
C632 168-2222-55 50V 2200pF
C641 168-1542-55 25V 0.15uF
C642 168-1542-55 25V 0.15uF
C643 168-1542-55 25V 0.15uF
C644 166-2201-50 50V 22pF
C645 166-2201-50 50V 22pF
C646 168-1542-55 25V 0.15uF
C647 166-2201-50 50V 22pF
C648 168-1542-55 25V 0.15uF
C649 168-1542-55 25V 0.15uF
C650 166-2201-50 50V 22pF
C651 168-1542-55 25V 0.15uF
C652 168-1542-55 25V 0.15uF
C701 168-1045-56 25V 0.1uF
C702 168-1045-56 25V 0.1uF
C703 168-1045-56 25V 0.1uF
C706 168-1045-56 25V 0.1uF
C707 168-1045-56 25V 0.1uF
C715 168-1045-56 25V 0.1uF
C716 168-1045-56 25V 0.1uF
C717 168-1045-56 25V 0.1uF
C718 168-1045-56 25V 0.1uF
C719 187-3343-65 50V 0.33uF
C720 168-1045-56 25V 0.1uF
C721 168-1045-56 25V 0.1uF
C722 187-4763-15 6.3V 47uF
C723 187-1063-35 16V 10uF
C724 166-2001-50 50V 20pF
C725 166-2001-50 50V 20pF
C726 168-1045-56 25V 0.1uF
C727 178-1052-78 16V 1uF
C728 168-1032-55 50V 0.01uF
C729 187-1063-35 16V 10uF
C730 178-1052-78 16V 1uF
C731 168-1032-55 50V 0.01uF
C732 187-2273-15 6.3V 220uF
C736 168-2222-55 50V 2200pF
C737 168-1045-56 25V 0.1uF
C801 166-1011-50 50V 100pF
C802 166-3311-50 50V 330pF
C803 166-1011-50 50V 100pF
C804 166-1011-50 50V 100pF
C805 166-1011-50 50V 100pF
C806 187-4763-15 6.3V 47uF
C807 168-1032-55 50V 0.01uF
C808 187-1053-65 50V 1uF
C809 168-1045-56 25V 0.1uF
C810 166-1501-50 50V 15pF
C811 166-1801-50 50V 18pF
C812 168-1022-55 50V 1000pF
C901 189-2283-32 16V 2200uF
C902 172-1041-15 50V 0.1uF
C903 187-1063-35 16V 10uF
C904 042-1598-90 10V 470uF
C905 187-2263-35 16V 22uF
C906 042-1598-90 10V 470uF
C907 187-1073-25 10V 100uF
C908 042-1452-81 10V 220uF
C910 042-1598-90 10V 470uF
C911 168-4732-78 50V 0.047uF
C914 168-1032-55 50V 0.01uF
C915 187-1063-35 16V 10uF
C927 042-1598-90 10V 470uF
C929 168-1045-56 25V 0.1uF
CCT201 050-0148-50 CCT 1K ohm
CCT202 050-0148-50 CCT 1K ohm
CCT203 050-0148-50 CCT 1K ohm
CCT204 050-0148-50 CCT 1K ohm
