Clarion M455 User Manual

M455 27
English
FM Tuner
Frequency Range:
U.S.A : 87.9 MHz to 107.9 MHz
Europe : 87.5 MHz to 108.0 MHz
Australia : 87.0 MHz to 108.0 MHz
Usable Sensitivity: 9 dBf
50dB Quieting Sensitivity: 15 dBf
Alternate Channel Selectivity: 70 dB
Stereo Separation (1 kHz): 35 dB
Frequency Response (±3 dB): 30 Hz to 15 kHz
AM Tuner
Frequency Range:
U.S.A : 530 kHz to 1710 kHz
Europe : 531 kHz to 1602 kHz
Australia : 531 kHz to 1629 kHz
Usable Sensitivity: 25 µV
CD Player
System: Compact disc digital audio system
Usable Discs: Compact disc
Frequency Response (±1 dB): 10 Hz to 20 kHz
Signal to Noise Ratio (1 kHz): 100 dB
Dynamic Range (1 kHz): 95 dB
Harmonic Distortion: 0.01%
Audio
Maximum Power Output: 208 W (52 W ✕ 4 ch)
Continuous Average Power Output:
17 W ✕ 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
Bass Control Action (60 Hz/100 Hz/200 Hz):
±15 dB
Treble Control Action (10 kHz/15 kHz): ±12 dB
Line Output Level (CD 1 kHz): 2 V
General
Power Supply Voltage: 14.4 V DC
(10.8 to 15.6 V allowable), negative ground
Current Consumption: Less than 15 A
Speaker Impedance: 4 Ω (4 Ω to 8 Ω allowable)
Weight / Source unit: 2.64 lb. (1.2 kg)
Dimensions / Source unit:
7" (Width) ✕ 2" (Height) ✕ 6-1/8" (Depth)
[178 (W) ✕ 50 (H) ✕ 155 (D) mm]
Note:
• Specifications and design are subject to change
without notice for further improvement.
11. SPECIFICATIONS
Source unit harness wire connections
RCA Connections
Wire Color Function
Yellow +12V DC Constant Power
Source/Memory
Red +12V DC Switch Lead/
Accessory
Black Ground
Blue/White Amplifier Remote Turn-on
Grey Right Front Speaker (+)
Grey/Black Right Front Speaker (–)
White Left Front Speaker (+)
White/Black Left Front Speaker (–)
Purple Right Rear Speaker (+)
Purple/Black Right Rear Speaker (–)
Green Left Rear Speaker (+)
Green/Black Left Rear Speaker (–)
Wire Color Function
Grey/Red Right Front Line Level
Output (Full range)
Grey/White Left Front Line Level
Output (Full range)
Black/Red Right Rear Line Level
Output (Full range or Sub
woofer)
Black/White Left Rear Line Level
Output (Full range or Sub
woofer)
Red/Red Right Auxiliary Input
Red/White Left Auxiliary Input
