13 Technical information
13.1 2 pipe system
Size 15 21 25 31 41 51 61 71
Cooling
Cooling capacity 1 kW 6.01 7.48 8.59 10.3 12.9 15.0 17.2 20.2
Sensible capacity 1 kW 4.57 5.56 6.16 8.10 9.95 11.1 13.3 14.9
Total power input 1 kW 0.16 0.16 0.16 0.31 0.31 0.31 0.46 0.46
Heating
Heating capacity 2 kW 7.82 9.47 10.0 13.9 17.2 18.3 23.1 24.6
Internal exchanger
Number of rows No 33433434
Water content l 1.90 2.00 2.70 2.90 3.00 4.00 4.00 5.30
Water ow-rate 1 l/s 0.29 0.36 0.41 0.49 0.62 0.72 0.82 0.97
Pressure drop 1 kPa 29 38 32 21 33 25 23 22
Air Handling Section Fans (Supply)
Type of supply fan 3 CFG CFG CFG CFG CFG CFG CFG CFG
Number of supply fans No 11122233
Supply airow 4 l/s 306 333 319 583 639 611 861 819
Supply airow 4 m3/h 1.100
1.200 1.150 2.100 2.300 2.200 3.100 2.950
Max. static pressure supply fan Pa 145 150 150 135 140 140 135 135
CONNECTIONS
Water ttings 3/4”F 3/4”F 3/4”F 3/4”F 3/4”F 3/4”F 3/4”F 3/4”F
Condensate drain 5 Ø 20 20 20 20 20 20 20 20
Power supply
Standard power supply V 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50
Noise Levels
Sound pressure level (1 m) 6 dB(A) 53 54 54 60 61 61 59 59
Sound power in the duct 6 dB(A) 64 65 65 71 72 72 70 70
1. Indoor air temperature at 27°C D.B./19°C W.B.. Water temperature in / out 7°C / 12°C. Air ow at maximum speed (ESP = 0Pa)
2. Indoor air temperature at 20°C. Water inlet temperature = 50°C. Air ow at maximum speed (ESP = 0Pa)
3. CFG = AC centrifugal fan
4. Air ow at maximum speed (ESP = 0Pa)
5. Intended as an external diameter
6. The sound levels refer to ceiling units without false ceiling, with nominal air ow, fan supply 220V, at maximum speed. Sound
pressure levels referred to 1 m. from unit external surface.
13.2 Operating range
Size 15 21 25 31 41 51 61 71
Heating
Max inlet water temperature [°C] 100 100 100 100 100 100 100 100
Min. entering water temperature [°C] 33333333
Max. inlet air temperature (D.B.) [°C] 40 40 40 40 40 40 40 40
Min entering air temperature (D.B.) [°C] 22222222
Cooling
Max entering air temperature (WB) [°C] 40 40 40 40 40 40 40 40
Min inlet air temperature (W.B.) [°C] 22222222
Maximum water side pressure bar 15 15 15 15 15 15 15 15
