INSTALLATION MANUAL 4600 CAN/PLIP
4
The list on the right side of the screen shows the product families. Clicking on the link you will get the full application list
available for the destination vehicle for the product family selected. Check at fi rst if there is a CAN application available, it
offers the best compromise amoung functionalities offered/fi tting time.
If no one CAN product installation proposal is available, make the same research clicking on “PLIP alarm” range AK4600
– 4400 Plip.
If there is an installation solution clicking on the vehicle model you can download the vehicle specifi c installation sheet.
If no one CAN and no one Plip installation proposal is available, choose again the vehicle type then, as “Product type” select
“Application manuals”. The list on the right side of the screen shows the application manuals available, click on “Application
manuals” to get the application manual list, then download the installation manual of the 4600 for the Plip confi guration.
3. - SYSTEM’S CONFIGURATION.
Be sure to have connected all Data Linker components and to have power supplied the system.
Run Antares.
As soon as Antares is starting, it automatically checks - if the computer is connected to internet - if the installed version is
the most updated one and, if not, it proposes its update.
We recommend to download all times the last update.
Proceed as follow:
A. Select the language.
B. Select “alarm and modules”.
C. Select product “4600 “ as “1 wire” or “2 wire”.
D. Select the procedure “fi rmware update”.
E. Click on “proceed”.
F. Select the vehicle brand.
G. Select the vehicle model.
H. Select the vehicle model year.
I. Click on “proceed”.
L. Confi rm and continue.
M. Wait until the programming confi rmation window appears.
Additional software installation and tool usage details are available on the specifi c manual supplied in the Data Linker kit
or in the Cobra web site, professional area, Application manuals.
