Illustrated Parts Catalog
Maintenance and Service Guide 3–17
Table 3-2
Miscellaneous Plastics/Hardware Kit Components
Spare Part Number 285261-001
(contains parts with silver finish for use with Presario 2800 models)
Spare Part Number 286868-001
(contains parts with carbon finish for use with
Evo Notebook N800c, N800v, and N800w models)
Item Description Item Description
1 Left hinge cover 9 Right display support
2 Right hinge cover 10 Connector cover
3 PC Card bezel 11 TouchPad bracket
4 PC Card slot space saver 12 Mini PCI compartment cover
5 Keyboard shield 13 Memory expansion
compartment cover
6 Display release assembly 14 Notebook feet (5)
7 Left display support 15 MultiBay weight saver
8 Fan channel 16 Docking connector cover
