ASSEMBLY
IMPORTANT: Thisunitisshippedwithoutgasolineoroilintheengine.Becertainto
serviceenginewithgasolineandoilasinstructedintheOperationsectionbefore
startingorrunningyourmachine.
NOTE: ReferencetorightandlefthandsideoftheLawnMowerisobservedfromthe
operatingposition.
OPENING CARTON
1. Cuteachcornerofthecartonverticallyfromtoptobottom.
2. Removealllooseparts.
3. Removeloosepackingmaterial.
REMOVING UNIT FROM CARTON
1. Liftunitfromthereartodetachitfromunderlyingcartonmaterialandroll
unitoutofcarton.
2. Checkcartonthoroughlyforanyotherlooseparts.
Loose Parts In Carton
• GrassCatcher
• SideDischargeCover
• EngineOil
Assembly
Attaching The Handle
1. Removeanypackingmaterialwhichmaybebetweenupperandlower
handles.
a. RemovehandknobsandcarriageboltshandleasshowninFigure1.
Donotloosenorremoveadjacenthexheadscrews.
b. Whilestabilizingmowersoitdoesn’tmove,pivotupperhandleupas
showninFigure2.Donotcrimpcablewhileliftingthehandleup.
2. RemoveT-boltsfromthehandlebracketsasshowninFigure3.
A
A
Figure 1
B
Figure 2
Figure 3
