PARTS LIST
Craftsman Model C459-60133
Ref.
No.
Part No. Description
1 925-1649 Bulb Socket
2 683-04619-4043 Hood Assembly
3 710-04484 Screw, 5/16-18 x .750
4 710-0599 Hex Washer Screw, 1/4-20 x .500
5 712-0292 Tin Clip Nut, 1/4-20
6 710-0751 Hex Screw, 1/4-20 x .620
7 710-05108 Screw, 1/4 x .750
8 712-04064 Nut, Hex Flange Insert Lock, 1/4-20
9 931-07668 Grill
10 731-07458 Headlight Lens, RH
11 731-07459 Headlight Lens, LH
12 731-07460 Dash Collar
13 731- 0 7711 Hood Scoop, LH
14 731-07712 Hood Scoop, RH
15 735- 0271A Bumper
16 738- 04091A Shoulder Screw, 5/16-18
17 783-05327B-0637 Left Support Pivot Bracket
18 783-05328A-0637 Right Support Pivot Bracket
19 783-06598-4043 Lower Grill
20 783-06610-0637 Lower Grill Bracket
21 983-04503 Speed Selector
22 710-05280 Self-Tap Screw, 1/4-20
23 710-3144 Hex Head Screw, 3/8-16
24 711- 07 36 Ferrule, 1/4-20 x 1.00
Ref.
No.
Part No. Description
25 712-04065 Nut, Hex Flange Insert Lock, 3/8-16
26 714-04040 Cotter Pin
27 783-06823 Speed Latch Support Tab
28 750-04465B Flange Spacer
29 783-04903A Speed latch
30 710-0604A Self-Tap Screw, 5/16-18
31 710-05108 Hex Screw, 1/4 x .750
32 712-04063 Nut, Hex Flange Lock, 5/16-18
33 731-04945 Steering Support
34 783-04873B-0637 Dash
35 747-05371 Fuel Tank Support Rod
36 747-05326 Dash support Rod
37 747-04430 Speed Selector Control Rod
38 751-0555B Fuel Tank
39 751-0603A Fuel Cap
40 783-04584B-0637 Gas Tank Support Bracket
41 731-05265 Choke Plug
42 746 -04364 Throttle/Choke Assembly
43 925-04659 Key Switch Module
44 625-04124 Key (2 pack)
45 725-0157 Cable Tie
46 925-0963 Headlight Bulb
47 726-04072A Ratchet Clip, .250 x .500
48 936-0463 Flat Washer, .25 x .630 x .0515
49 710-1652 Hex Washer Screw, 1/4-20 x .625
