43
PARTS LIST
Craftsman Model C459-60133
Ref.
No.
Part No. Description
1 918-04822A Spindle Pulley Assembly
2 683-0254B-0637 Deck Hanger Bracket Assembly
3 710-0642 Screw, 1/4-20 x .750
4 983-04511 Brake Assembly
5 983-04525 Brake Assembly
6 983-04570-0637 Deck
7 710-04484 Screw, 5/16-18 x .750
8 710-0514 Screw, 3/8-16 x 1.00
9 710-0528 Hex Screw, 5/16-18 x 1.25
10 710-0599 Screw, 1/4-20 x .500
11 710-0778 Screw, 1/4-20 x 1.50
12 710-3144 Hex Head Screw, 3/8-16
13 710-3178 Carriage Bolt, 3/8-16 x .75
14 712-0229 Push Nut, 3/8
15 712-04063 Flangelock Nut, 5/16-18
16 712-04065 Flangelock Nut, 3/8-16
17 712-0417A Flange Nut, 5/8-18
18 712-04243 Flangelock Nut, 1/2-13
19 912-0641 Hex Nut, M16 - 1.5
20 714-04043 Cotter Pin, Bow-Tie
21 917-04074 Deck Adjuster Gear
22 932-0384 Extension Spring, .62 x 6.12
23 732-04727 Torsion Spring, 1.0 x 1.17
24 936-0119 Lock Washer, 5/16
25 736-0187 Flat Washer, .64 x 1.24 x .06
26 736-0225 Flat Washer, .5/8 Int. Tth.
27 736-0262 Flat Washer, .385 x .870 x .092
28 936-0344 Flat Washer, .385 x 1.0 x .030
Ref.
No.
Part No. Description
29 736-0362 Flat Washer, .330 x 1.25 x .06
30 738-04146 Bolt Plug, M16 x 1.5
31 738-04162A Shoulder Spacer, .8840 x .190
32 942-04308 Cutting Blade, 21.23”: 2 in 1
33 747-05105 Brake Control Rod
34 747-05141A Deck Lift Rod
35 747-05323 Belt Keeper Rod
36 748-0234 Shoulder Spacer
37 748-04069 Deck Lift Pivot Cup
38 750-0258 Spacer
39 750-0566A Spacer
40 954-04060B V-Type Belt, 96.5
41 756-04129B Idler Pulley, 4.25 Diameter
42 783-05946 Idler Pivot Bracket
43 783-06243-0637 Deck Cable Engagement Bracket
44 783-06368A-0637 Belt Pulley Guard
45 783-06424A-0637 Deck Belt Cover
46 783-06643-0637 Deck Support Bracket
47 631-04288 Chute Deflector Assembly
48 711-04847B Hinge Pin
49 732-04372 Torsion Spring, .44 x 2.0
50 783-06074A Chute Bracket
51 936-0351 Flat Washer, .760 x 1.50
52 738-1186A Spindle Shaft
53 941-0919 Ball Bearing, .787 x 1.85 x .551
54 750-04936 Spacer, .792 x 1.060 x 1.860
55 956-1227 Deck Pulley, 6.3 dia.
