Craftsman CMCS500 User Manual

1
ENGLISH
English (original instructions)
LangRef_U_NA_U_U-ENG
COMPONENTS
1
On/off switch
2
Lock off button
3
Main handle
4
Secondary handle
5
Shoe
6
Saw blade
7
Lower blade guard with
depth scale
8
Lower guard retracting
lever
9
Bevel adjustment knob
10
Bevel angle scale
11
Outer blade clamp
washer
12
Blade retaining bolt
13
Depth adjustment lever
14
Spindle lock button
15
Battery
16
Battery release button
17
Hex wrench
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.

WARNING: Never modify the product or any part of it.
Damage or personal injury couldresult.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this or
any product, call CRAFTSMAN toll free at:
1-888-331-4569.
Fig. A
1
3
15
16
2
4
5
6
8
9
10
11
12
17
14
13
7

Craftsman CMCS500 Specifications

General

Brand	Craftsman
Model	CMCS500
Category	Saw
Language	English
