Craftsman Z6800 User Manual

2
3
4
5
14
13
12
11
10
9
8
7
1
6
This operator manual describes the Craftsman
Zero Turn Rider. The rider is tted with a four-
stroke overhead valve engine.
Transmission from the engine is made via
belt-driven hydraulic pumps. Using the left and
right steering controls, the ow is regulated and
thereby the direction and speed.
1. Motion control levers
2. Park brake
3. Tracking knob
4. Fuse
5. Bypass Linkages
6. Fuel shut off
7. Fuel tank
8. Blade switch
9. Ignition switch
10. Throttle
11. Choke
12. Service meter
13. Seat adjustment lever
14. Deck lift
12
CONTROLS

Craftsman Z6800 Specifications

General

Brand	Craftsman
Model	Z6800
Category	Lawn Mower
Language	English
