Dixie-Narco Factory Setup Menus - BevMax Setup/Test Modes
The below diagnostic features are used for aligning the XY assembly and providing pertinent information that is
unique to the Coca-Cola BevMax 4 Vender and is not found in the standard programming of the vender. These
include menus for “BevMax Setup”, Test Modes”. The menus include the following sub-menus. In BevMax Setup
you have “Set Price/Temperature 4 Test”, “Set Price/Temperature Default”, “Set Shelf Offset”, “Position Test”,
“Set Hook Offset”, “Cup Sensor On/Off”, “Cup Test”, “Port Test”, “Set Shelf Configuration”, “Master Reset”,
“Update Software”, “Double Talk”, and “Build Number ###”. In Test Modes you have “Test Vend”, “Test Sel
Switch”, “Test Display”, and “Test Relays”.
To enter “BevMax Setup” sub menus:
Press the service switch on the controller (Blue button on the control board). When the display reads "Error
Codes" press and let go of the following keys in order; "1" "5" "1" "5" "1". If the keys were actuated correctly, the
VMC will enter the factory diagnostic mode and the display will read "BevMax Setup". Press the number 2 key to
scroll to Test Modes or press the number "4" key one time will cause the VMC to enter the BevMax Setup sub
menu or press and hold the number "1" key for 1 second to exit the "BevMax Setup" submenu and return to the
"Error Codes" service menu prompt. Once you enter the "BevMax Setup" mode press key 4 to enter submenu
and Coke Factory Setup Set Prc/Tmpr 4 Test will show on display, press and hold the number "2" key and the VMC
will begin to cycle forward through the available options or press and hold the number “3” key to cycle backwards
through the available options. Press key 4 one time at any option for the VMC to enter that option.
BevMax Setup
Coke Factory Setup
Set Model Number
This sub menu will be used to set the model number of the vender in the control board so it knows the vender
configuration. Press key number “4” to enter the menu and the display will show “Reset Model? Continue? 4 = Y
(yes) 1 = N (no). If you select 4 (yes) the display will show a model number (example 5800-4) Save? A = ^, = Y
(yes), CLR = N (no). Press the key “A” to scroll through all the available models 5800-4, 3800-4, 5800-E4, 3800-E4.
With the display showing the vender model number you wish to save press the key. Note: program model
number 5800-4 for all BevMax 3/2 venders with 9 columns on each tray. There is not a 5800 model number
available for the Bevmax 3/2 Venders.
Coke Factory Setup
Set Prc/Tmpr 4 Test – (DO NOT USE IN THE FIELD)
This sub menu will be used to set the vend price and temperature during our factory testing and should not be
used in the field.
Coke Factory Setup
Set Prc/Tmpr Default – (DO NOT USE IN THE FIELD)
This sub menu will be used to set the vend price and temperature back to factory default settings during our
factory testing and should not be used in the field. Press key 4 and display will show “Set To Default? Continue?
4=Y 1=N. Press key 4 to set price and temperature settings to factory default settings.
Coke Factory Setup
Set Shelf Offset – Test Delivery Cup to Shelf Alignment:
This sub menu will be used to set the XY to the proper shelf height. Press key number "4" one time at the “Shelf
Offset” prompt. The VMC will enter the shelf adjust option and display the current shelf offset position as “Shelf
Offset: 900 3310 counts = 1 inch”. To adjust Shelf (Y) Offset (up and down), enter a new number and press the
