Crown XTi 4002 User Manual

XTi2 Series Power Amplifiers
page 9
Operation Manual
Fans:
Provide front to back
forced airflow for cooling.
Input Connector:
Two 3-pin XLR input
connectors are provided
(one per channel).
4-Pole Speakon
®
Output Connectors:
These two connectors accept 2-pole and 4-pole
Speakon© connectors. The channel 1 connector is
wired for both channels so it can be used for
bridge-mono wiring or stereo wiring of two
speakers to a single Speakon.
Link/Out Connector:
Two 3-pin XLR output
connectors are provided
(one per channel) to
loop-thru signal from one
amplifier to another.
HiQnet USB Connector:
Type B USB connector allows
you to connect the amplifier to
a computer for use with
System Architect
™ and Band
Manager
™ software.
Circuit Breaker:
Provides overload protection
4-Pole Speakon
®
Output Connectors:
These two connectors accept 2-pole and 4-pole
Speakon© connectors. The channel 1 connector is
wired for both channels so it can be used for
bridge-mono wiring or stereo wiring of two
speakers to a single Speakon.
Link/Out Connector:
Two 3-pin XLR output
connectors are provided
(one per channel) to
loop-thru signal from one
amplifier to another.
HiQnet USB Connector:
Type B USB connector allows
you to connect the amplifier to
a computer for use with
System Architect
™ and Band
Manager
™ software.
Binding Post Output Jacks:
One pair per channel, accepts banana plugs or
bare wire. Note: Binding Post outputs on European
models come with safety plugs installed to prevent
European power plugs from being inserted. The
side entry positions for these connectors should
be used with European models.
Fans:
Provide front to back
forced airflow for cooling.
Input Connector:
Two 3-pin XLR input
connectors are provided
(one per channel).
Binding Post Output Jacks:
One pair per channel, accepts banana plugs or
bare wire. Note: Binding Post outputs on European
models come with safety plugs installed to prevent
European power plugs from being inserted. The
side entry positions for these connectors should
be used with European models.
AC Power
Connector
Power Cord Clip:
Mounting points for
securing, included
power cord clip.
AC Power
Connector
Power Cord Clip:
Mounting points for securing,
included power cord clip.
Back Panel Features
XTi 1002, 2002, 4002
XTi 6002

Crown XTi 4002 Specifications

General

Damping factor	500
Amplifier class	-
Input sensitivity	1400 mV
Audio output channels	2.0 channels
Peak power per channel	1600 W
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.5 %
RMS power output per channel (4 Ohm)	1200 W
RMS power output per channel (8 Ohm)	650 W
Bridge-mode power output per channel (4 Ohm)	3200 W
Bridge-mode power output per channel (8 Ohm)	2400 W
Built-in display	Yes
Maximum current	15 A
Package weight	9800 g
Purpose	Home
Product color	Beige
Connectivity technology	Wired

Weight and Dimensions

Depth	311 mm
Width	483 mm
Height	89 mm
Weight	8400 g
