Cub Cadet 21AA40M7710 Parts Manual

1717
Model Series 450
Ref.
Part Number Description
1. 747-1152 Shaft Rod
2. 649-0034 Lower Handle Tube Assembly
3. 649-0041 Upper Handle Assembly
4. 710-0946 Screw, 1/4-20 x 0.625
5. 710-3005 Hex Head Screw, 3/8-16:1.25
6. 710-3056 Hex Head Screw, 5/16-18 x 3.25
7. 911- 0 415 Clevis Pin, .375 X 1.75
8. 712-0324 Hexlock Nut, 1/4-20
9. 712- 0379 Flangelock Nut, 3/8-24
10. 912-0429 Hexlock Nut, 5/16-18
11. 710-1307 Stud, 5/16-18 x .75
12. 720-0210A Small Tee Knob
13. 720-0278A Foam Grip, .970 x 11.0
14. 720 -0313 Grip, .1875 x 1.00
15. 726-0273 Battery Clamp, 5/16
16. 726- 0317 Cable Tie, 8.5 LG
17. 735-0246A End Plug
18. 936 - 0117 Washer, Flat, .385 x .620 x .033
19. 736-0242 Washer, Bell, .340 x .872 x .060
20. 736-3090 Washer, Flat, .260 x .720 x .060
21. 938-0958 Spacer, Shoulder, .50 x .190 x .360
22. 747-1219 Clutch Bail
23. 784-0190 Handle Adjustment Crank
24. 784-0191 Hex Nut Retainer Bracket
25. 786-0120 Tiller Depth Control
26. 786-0181 Shaft Rod Lever
27. 735-0127 Washer, Rubber, .33 ID x .125
28. 914-0104 Cotter Pin, .072 x 1.12 LG
29. 686-0044B End Cover Assembly
30. 710 -0176 Hex Head Screw, 5/16-18 x 2.75
31. 710-3008 Hex Head Screw, 5/16-18 x .75
32. 710-3022 Hex Head Screw, 3/8-16 x 2.75
Ref.
Part Number Description
33. 710-04482 Hex Head Flange, 3/8-16 x .875
34. 712- 04063 Flangelock Nut, 5/16-18
35. 712- 04065 Flangelock Nut, 3/8-16
36. 712-0421 Wing Nut, 5/16-18 W/ Bell Washer
37. 926-0106 Speed Nut Cap, 1/4 ROD
38. 736-0204 Washer, Flat, .344 x .62 x .033
39. 938-0849 Screw, Hex, 5/16-18 x .75
40. 747- 0432 Tiller Flap Rod
41. 750-0885A Spacer, .322 x .625 x 2.00
42. 786-0090A Side Shield
43. 786 - 0113A Rear Tine Shield
44. 786 - 0176 RH Handle Mount Bracket
45. 786- 0177 LH Handle Mount Bracket
46. 786-0178A Tine Shield
47. 786-0179 FRT Tine Shield Bracket
48. 786-0180 FRT Tine Shield Spacer Bracket
49. 686-0109A Shift Crank Assembly
50. 710-1652 Screw, ⁄-20 x .625
51. 715-0120 Spiral Pin, ⁄ x 1.0
52. 784-0208D Shift Cover
53. 911- 0 415 Clevis Pin
54. 712-3054 Hex Nut, ⁄-24
55. 742-0305A 13” Articulating Tine
56. 938-0689 Shoulder Bolt
57. 936-0253 Bell Washer, .515” ID x 1.14” OD
58. 938-0688 Shoulder Bolt
59. 784-0160 Tine Adapter Assembly, 18”
60. 714-04043 Internal Cotter Pin
61. 936-0169 Lock Washer
62. 784-0161 Tine Adapter Plate
63. 731-07556 Cap
64. 936-0208 Washer, Flat, .51 x 1.5 x .07
