Cub Cadet 21AA40M7710 Parts Manual

88
170-VU Cylinder Head
Ref.
Part Number Description
1 710-04968 Bolt M6×16
2 951-11054 Valve Cover
3 726-04101 Breather Hose Clamp
4 731-07059 Exhaust Piping
6 951-11565 Valve Cover Gasket
7 951-11892 Rocker Arm Assembly
8 751-11124 Nut, Pivot Locking
9 751-1112 3 Adjusting Nut ,Valve
10 951-11893 Rocker Arm
11 710-04902 Bolt, Pivot
12 951-11895 Push Rod Guide
13 951-12000 Retainer, In.Valve Spring
14 951-12002 Adjuster, Exh Valve
15 951-12003 Retainer, Ex.Valve Spring
16 951-12004 Valve Spring
17 951-11894 Intake Valve Seal
18 710-04933 Bolt M8×55
19 951-10722A Cylinder Head Assembly
1
1
1
2
6
126
1
3
4
7
8
9
10
11
8
9
10
11
12
17
19
18
18
18
18
20
46
49
49
50
51
47
47
48
48
16
16
15
14
13
128 - Cylinder Head Service Kit
129 - Gasket Kit - External
130 - Gasket Kit - Complete
131 - Complete Engine

Cub Cadet 21AA40M7710 Specifications

General

Brand	Cub Cadet
Model	21AA40M7710
Category	Tiller
Language	English
