Cub Cadet CCR400 User Manual

16
ASSEMBLY AND OPERATING
ADJUSTING THE FRONT HANDLE
The front handle can be adjusted to suit
the operator (Fig. 1).
1. Using a Torx® screwdriver (1), turn
the four handle clamp screws (2)
counter clockwise until the handle
(3) will rotate on the trimmer outer
shaft (4) (Fig. 1).
2. Slide the handle up or down and/or
rotate it to a comfortable position.
Make sure the handle is positioned
beyond the end of the safety label (5).
3. Re-tighten the handle clamp screws
to hold the handle in the desired
position.
NOTE: Do not over tighten the clamp
screws. You will break the clamp.
Instructions for charging the Power Cell are packed with the charger.
WARNING: Read all safety warnings and charging instructions included with
the charger.
Fig. 1
1
3
4
2
5

Cub Cadet CCR400 Specifications

General

Brand	Cub Cadet
Model	CCR400
Category	Trimmer
Language	English
