Cub Cadet Volunteer User Manual

Service
6
21
Fuses
1. Unlatch and lift hood forward to get access to under the
dash panel.
2. Remove fuse holder cover. See Figure 6-17.
Figure 6-17
3. Remove the appropriate electrical fuse and replace with
proper amperage fuse.
4. Lower and secure hood.
Headlight Bulbs
1. Raise hood to get access to the headlight assembly.
2. Turn the bulb/socket assembly approximately a quarter
turn counterclockwise to align its tabs with the notches of
the reflector, then remove from the reflector. See Figure
6-16.
Figure 6-16
3. Unplug the wire harness from the bulb/socket assembly.
4. Plug the new bulb/socket assembly into the wire harness.
5. Align the tabs of the new bulb/socket assembly with the
notches of the reflector and insert the bulb. Turn the bulb/
socket assembly clockwise to lock in place.
6. Lower and secure hood.
