Current Tools 11 User Manual

6
FEATURES
• Quickly mount most battery powered drills for use
• Easily remove pulling line from capstan after use
• Complete unit with no assembly required
• Maintenance free gearbox
• Quick length adjustment for different jobs
• Light weight — cable puller weighs approximately 16 lbs. (without drill)
• One person operation
• Mounting coupling for adding stabilizing leg
SPECIFICATIONS
Model no. — 11
Width — 10"
Height — 14.5"
Fully extended length — 55"
Retracted length — 37.25"
Weight — 16 lbs. – puller only (no drill)
Maximum pulling force — 1,000 lbs.
Conduit size range — 1/2"– 4"
Speeds — no load
Low – 10 ft./min.
High – 38 ft./min.
Pulling rope — minimum rated capacity of no less than 1,500 lbs.
and an average breaking strength of 6,000 lbs.
— rope diameter of 1/4" to 1/2"
Pulling line — use mule tape, measuring tape or poly line rated
for the application
