10
7. CONNECTION DIAGRAM
1
HDMI IN
DC 5V
12345678
EDID
STDTV
HDMI OUT
DVD or Blu-ray Player
HDTV
HDTV
HDTV
HDTV
Projector
Projector
Projector
Projector
Power
Supply
Simultaneous
HDMI Outputs
HDMI
Input
