D-Link DAP-1530 Quick Installation Guide

DAP-1530
3
ENGLISH
PRODUCT SETUP
SETUP
SET UP DAP-1530 WITH QRS MOBILE APP
The DAP-1530 can be congured using your smartphone. Search for "D-Link QRS
Mobile" on the Apple App Store or Google Play, and download the app. Next, connect
your smartphone to the DAP-1530 using the SSID and Password information
provided on the Wi-Fi Conguration Card and follow the helpful in-app prompts, or
refer to the product manual for more information.
SET UP DAP-1530 WITH A WEB BROWSER
The DAP-1530 can also be configured using a web browser. Once you have
plugged the DAP-1530 into a wall outlet within wireless range of your router
or connected to your existing wired network, open the wireless utility on
your computer, select the name (SSID) of the DAP-1530 network, and enter
the password (both of these are found on your Wi-Fi Configuration Card).
Next, open a web browser (e.g. Internet Explorer, Firefox, Safari, or Chrome) and
enter http://dlinkap.local./ By default, the username is Admin, and the password
eld should be left blank. Please refer to the product manual for further information
on conguring the DAP-1530 using a web browser.
TROUBLESHOOTING
SETUP AND CONFIGURATION PROBLEMS
1. HOW DO I RESET MY DAP-1530 AC750 PLUS WI-FI RANGE EXTENDER TO FACTORY
DEFAULT SETTINGS?
- Ensure the product is powered on.
- Using a paperclip, press and hold the reset button on the bottom of the device for 5
seconds.
Note: Resetting the product to the factory default will erase the current conguration
settings. The default Wi-Fi network name (SSID) and password are printed on
the DAP-1530's Wi-Fi Conguration Card.
2. HOW DO I CONNECT A PC OR OTHER DEVICE TO THE DAP-1530 IF I HAVE FORGOTTEN
MY WI-FI NETWORK NAME (SSID) OR WI-FI PASSWORD?
- If you haven't changed the extended Wi-Fi network's settings, you can use the
network name (SSID) and Wi-Fi password on the Wi-Fi Conguration Card.
- If you did change the network name (SSID) or Wi-Fi password and you did not record
this information on the Wi-Fi Conguration Card or somewhere else, you must reset
the device as described in Question 1 above.
- It is recommended that you make a record of this information so that you can easily
connect additional wireless devices in the future. You can use the included Wi-Fi
Conguration Card to record this important information for future use.

D-Link DAP-1530 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Antenna type	External
Antennas quantity	2
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3ab
Wi-Fi data rate (max)	433 Mbit/s
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Flash memory	8 MB
Internal memory	64 MB
Certification	FCC, CE, IC, UL
Product color	Grey, White
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	48.7 mm
Width	50.7 mm
Height	97.9 mm
Weight	116 g
