D-Link DAP-1820 User Manual

2 DAP-1820 Install Guide
Package Contents
DAP-1820 AC2000 Mesh Wi-Fi Range Extender
Quick Install Card
Quick Install Guide
If any of the above items are missing, please contact your reseller.
• For setup, you will want your Range Extender to be plugged into
an available outlet as close to your Wi-Fi Router as possible. Once
setup is complete, you can plug it into an outlet in the area between
your Wi-Fi router and where you want improved coverage. See the
Troubleshooting section for tips on Wi-Fi Extender placement.
• If your wireless router or access point does not have a
WPS button ( , ), follow the steps under Method Two: D-Link
Wi-Fi Setup to set up your Range Extender.
Before You Begin

D-Link DAP-1820 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Security algorithms	WPA, WPA2
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN (RJ-45) ports	1
Certification	FCC, UL, IC, CB, CE
Product color	White
Antenna type	External
Antennas quantity	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	85.4 mm
Width	140 mm
Height	48.6 mm
Weight	274 g
