D-Link DAP-1820 User Manual

DAP-1820 Install Guide 7
Signal Strength Indicator
Very Weak (1 x Amber) Weak (1 x Green) Good (2 x Green) Strong (3 x Green)
Your setup is complete! You can now unplug and move your Range Extender to a
location between your Wireless Router and the area where you want wireless coverage.
By default, your Range Extender will share the same name and password as your
Router.
If after moving your Range Extender, the signal strength indicator is showing one
single amber bar or if your Range Extender LED does not turn solid green within 3
minutes, move your Range Extender to a wall outlet closer to your wireless router.

D-Link DAP-1820 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Security algorithms	WPA, WPA2
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN (RJ-45) ports	1
Certification	FCC, UL, IC, CB, CE
Product color	White
Antenna type	External
Antennas quantity	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	85.4 mm
Width	140 mm
Height	48.6 mm
Weight	274 g
