D-Link DCS-6010L User Manual

30D-Link DCS-6010L User Manual
Section 3: mydlink
Select this option to enable the automatic recording when motion
is detected.
Add Detection Area: Click on this icon to draw areas that
will trigger automatic recording when motion is detected.
Remove Detection Area: Click on this icon to erase areas
from regions that trigger automatic recording when
motion is detected.
Clear Detection Area: This will remove all detection areas
Refresh Snapshot: This will refresh the current snapshot
of the monitored area.
Increase/Decrease Sensitivity Increase the motion
detection sensitivity
Toggles notication by email on or o.
In the event that the microSD card can not store further recordings,
the user can choose to record over previous recordings or to be
notied and cease recording.
Record video clips
when motion is
detected:
Email Notication:
Video Clips Recording
Mode:
Recording Settings

D-Link DCS-6010L Specifications

General

Total megapixels	2 MP
Maximum resolution	1600 x 1200 pixels
Supported video modes	-
Video formats supported	H.264, MPEG4
Supported graphics resolutions	800 x 600 (SVGA)
Sensor type	CMOS
Optical sensor size	1/3.2 \
Optical zoom	- x
Zoom capability	Yes
Fixed focal length	1.25 mm
Minimum illumination	2 lx
Form factor	Dome
Mounting type	Ceiling
Product color	White
AC input voltage	100-240 V
DC output current	1.2 A
DC output voltage	+5V
Power source type	PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	3.9 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Compatible memory cards	SD, SDHC
Cabling technology	10/100Base-T(X)
Networking features	10/100Mbps Fast Ethernet
Certification	CE, CE LVD, FCC, C-Tick
GPS (satellite)	No
Placement supported	Indoor
Connectivity technology	Wireless

Weight and Dimensions

Width	134.2 mm
Height	49.8 mm
Weight	1920 g
