Appendix A: Technical Specications
Technical Specications
Camera
Hardware Profile • 1/2.7” Megapixel progressive CMOS sensor
• 5 m (16 ft) IR illumination distance
• Minimum illumination:
• B/W (Night Mode), IR LEDs on: 0 lux
• Built-in Infrared-Cut Removable (ICR) Filter module
• Fixed length 2.7 mm
• Aperture F2.4
• Angle of view
• Horizontal: 137°
• Vertical: 71°
• Diagonal: 167°
• Built-in microphone
• Built-in speaker
Image Features • Configurable image size
• Configurable sound level detection
• Configurable motion detection windows
Video Compression • Simultaneous H.264/MJPEG format compression • JPEG for still images
Video Resolution • Main Profile: 1080P (1920 x 1080) at up to 30 fps • Second Profile: 720P (1280 x 720) at up to 15 fps
Audio Support • MPEG-2 AAC LC
Network
Connectivity • 802.11n/g/b wireless with WPA/WPA2 encryption1
• Operates on 2.4 GHz band
• microSD card slot
2
• Single-band 2T2R mode supports a maximum data
• rate of 72.2 Mbps (PHY rate) using 20 MHz bandwidth1
• Bluetooth 2.1/3.0/4.0
Network Protocols • IPv4, IPv6, ARP, TCP, UDP, ICMP
• DHCP Client
• DNS Client
• RTP, RTSP/SRTP
• HTTPS
• Bonjour
System Integration
Event Management • Motion detection
• Sound detection
• Cloud recording
• Manually taken snapshots and video clips are saved to mobile device
• Push Notification
Mobile Support • mydlinkTM app for iPhone, iPad, and Android phone and tablet • Manually taken snapshots and video clips are saved to mobile device
• Push Notification

D-Link DCS-8300LH Specifications

General

Type	IP security camera
Certification	CE, CE LVD, RCM, FCC Class B, ICES
Remote viewing	Yes
Placement supported	Indoor
Connectivity technology	Wireless
Form factor	Spherical
Mounting type	Desk
Product color	White
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264, M-JPEG
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Minimum illumination	0 lx
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.7 \
LED type	IR
Night vision distance	5 m
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Ethernet LAN	-
Frequency band	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Supported network protocols	IPv4, IPv6, ARP, TCP, UDP, ICMP, RTP, RTSP, HTTPS
Audio formats supported	AAC
AC input voltage	100 - 240 V
DC output current	1.2 A
DC output voltage	5
Power source type	AC, DC
AC input frequency	50 - 60 Hz
Power consumption (max)	5 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Fixed focal length	2.7 mm
Maximum aperture number	2.4
Security algorithms	WPA, WPA2
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1413 mm
Pallet height (sea)	1981 mm
Pallet gross weight (air)	264000 g
Pallet gross weight (sea)	372000 g
Quantity per pallet (air)	540 pc(s)
Quantity per pallet (sea)	780 pc(s)
Shipping (inner) case width	199 mm
Shipping (inner) case height	142 mm
Shipping (inner) case length	472 mm
Shipping (inner) case weight	2250 g
Shipping (inner) case net weight	1900 g
Number of cartons per pallet (air)	108 pc(s)
Number of cartons per pallet (sea)	156 pc(s)
Mobile operating systems supported	Android, iOS
Harmonized System (HS) code	85258900
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	66 mm
Width	109 mm
Weight	105 g
Package depth	183 mm
Package width	110 mm
Package height	89 mm
Package weight	410 g
