D-Link DES-1016D User Manual

10/100 NWay Ethernet/Fast Ethernet Switch User’s Guide
Introduction 1
1
1 I
NTRODUCTION
This section describes the features of the Switch.
Features
The Switch is designed for easy installation, a superior
cost/performance ratio, and easy migration to a bandwidth-critical
environment where traffic on the network and the number of users
increases continuously.
The Switch supports auto-negotiation, allowing both 10Mbps and
100Mbps operation in full-duplex or half-duplex mode, even on all
ports simultaneously.
Low price and compact dimensions make the Switch suitable for
small and medium-size workgroups as well as SOHO
environments, enabling users to migrate easily from traditional
shared LANs to switched networks. Each full/half duplex port can
be connected directly to high-demand nodes, such as workstations,
servers, or other switches or hubs, to meet increased bandwidth
and flexibility demands.
The Switch performs store-and-forward switching to ensure
effective buffer allocation for each port. Data flow is controlled
between the transmitting and receiving nodes to guarantee
against all possible packet loss.

D-Link DES-1016D Specifications

General

MAC address table	8000 entries
Store-and-forward	Yes
Maximum data transfer rate	0.2 Gbit/s
10G support	No
Networking standards	IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
Internal memory	2 MB
Mean time between failures (MTBF)	2266559 h
Heat dissipation	9.86 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC Class A, ICES-003 Class A, CE Class A, C-Tick Class A, VCCI Class A, LVD, cUL
Product color	Black
LED indicators	Activity, Link, Power, power
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	16
Switch type	Unmanaged
Switch layer	-
Supported network protocols	CSMA/CD
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	2.89 W
Package depth	376 mm
Package width	282 mm
Package height	78 mm
Package weight	1800 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1379 mm
Pallet height (sea)	2001 mm
Pallet gross weight (air)	253880 g
Pallet gross weight (sea)	372320 g
Quantity per pallet (air)	120 pc(s)
Quantity per pallet (sea)	180 pc(s)
Shipping (inner) case width	392 mm
Shipping (inner) case height	311 mm
Shipping (inner) case length	420 mm
Shipping (inner) case weight	9870 g
Shipping (inner) case net weight	9000 g
Number of cartons per pallet (air)	24 pc(s)
Number of cartons per pallet (sea)	36 pc(s)
Quantity per shipping (inner) case	5 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	125.8 mm
Width	280 mm
Height	44 mm
