D-Link DES-1016D User Manual

warrants the magnetic media, on which D-Link provides its software product, against failure
during the same warranty period. This warranty applies to purchased software, and to
replacement software provided by D-Link pursuant to this warranty, but shall not apply to any
update or replacement which may be provided for download via the Internet, or to any update
which may otherwise be provided free of charge.
D-Link's sole obligation under this software warranty shall be to replace any defective software
product with product which substantially conforms to D-Link's applicable product
documentation. Purchaser assumes responsibility for the selection of appropriate application
and system/platform software and associated reference materials. D-Link makes no warranty
that its software products will work in combination with any hardware, or any application or
system/platform software product provided by any third party, excepting only such products as
are expressly represented, in D-Link's applicable product documentation as being compatible.
D-Link's obligation under this warranty shall be a reasonable effort to provide compatibility, but
D-Link shall have no obligation to provide compatibility when there is fault in the third-party
hardware or software. D-Link makes no warranty that operation of its software products will be
uninterrupted or absolutely error-free, and no warranty that all defects in the software product,
within or without the scope of D-Link's applicable product documentation, will be corrected.
D-Link Offices for Registration and Warranty Service
The product's Registration Card, provided at the back of this manual, must be sent to a D-Link
office. To obtain an RMA number for warranty service as to a hardware product, or to obtain
warranty service as to a software product, contact the D-Link office nearest you. An
address/telephone/fax/e-mail/Web site list of D-Link offices is provided in the back of this manual

D-Link DES-1016D Specifications

General

MAC address table	8000 entries
Store-and-forward	Yes
Maximum data transfer rate	0.2 Gbit/s
10G support	No
Networking standards	IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
Internal memory	2 MB
Mean time between failures (MTBF)	2266559 h
Heat dissipation	9.86 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC Class A, ICES-003 Class A, CE Class A, C-Tick Class A, VCCI Class A, LVD, cUL
Product color	Black
LED indicators	Activity, Link, Power, power
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	16
Switch type	Unmanaged
Switch layer	-
Supported network protocols	CSMA/CD
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	2.89 W
Package depth	376 mm
Package width	282 mm
Package height	78 mm
Package weight	1800 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1379 mm
Pallet height (sea)	2001 mm
Pallet gross weight (air)	253880 g
Pallet gross weight (sea)	372320 g
Quantity per pallet (air)	120 pc(s)
Quantity per pallet (sea)	180 pc(s)
Shipping (inner) case width	392 mm
Shipping (inner) case height	311 mm
Shipping (inner) case length	420 mm
Shipping (inner) case weight	9870 g
Shipping (inner) case net weight	9000 g
Number of cartons per pallet (air)	24 pc(s)
Number of cartons per pallet (sea)	36 pc(s)
Quantity per shipping (inner) case	5 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	125.8 mm
Width	280 mm
Height	44 mm
