D-Link DPR-1061 User Manual

68
TCP/IP
This field contains four options that allow you to configure the TCP/IP setting: DNS
Server Address, UPnP, Mac Bonjour/Rendezvous, and Second HTTP Port.
 UPnP: This option allows you to enable or disable UPnP function.
 Mac Bonjour/Rendezvous: This option allows you to enable or disable Mac
Bonjour/Rendezvous function.
 Second HTTP Port: This option allows you to enable or disable Second HTTP
Port for remote Web Configuration and IPP Printing.
Microsoft Network
Enter the name of the Workgroup that you want the print server associated with in
this field.
AppleTalk
Enter the AppleTalk Zone name in the box. In the following options, enter the related
configuration, such as the printer type.
Chooser Name
: Display the print server's port name.
Printer Type
: Enter the printer's type in this box.
PostScript Level
: Select from the pull-down menu (Level 1 or Level 2).
Font Group
: Select from the pull-down menu.
Once you have changed the settings in each option, click Apply Settings to store the
settings, or Cancel to abandon.

D-Link DPR-1061 Specifications

General

Networking standards	IEEE 802.3
Network connection type	Ethernet LAN
Supported network protocols	TCP/IP, NetBEUI, IPP
Interface	10/100Base-TX
Dimensions (WxDxH)	192.5 x 118.4 x 31 mm
Power requirements	5.0V DC/2.5A
Compatible operating systems	Windows Vista/XP/2000/NT 4/ME/98SE/95 Apple Mac OS 9.x - MAC OS X 10.4.x Linux UNI X lpr/lpd (HP-UX, SunOS, Solaris, SCO, UnixWare, IBM AIX) NetWare 5.x
DC-in jack	Yes
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 50 °C
Certification	FCC, CE, C-Tick, IC, CSA

Weight and Dimensions

Depth	118.4 mm
Width	192.5 mm
Height	30.1 mm
Weight	292 g
